Council Meeting/Documents/Attachment 10 - Typical Type A Elevations
Appendix

Attachment 10 - Typical Type A Elevations

February 2, 2016Page 341 section

Detailed drawings of the front, rear, and side elevations for Type A buildings.

8.1.a Development Permit No. 2015/12 - 102 Atkins Road
Scale 1/4" = 1'0"January 25, 2016

TYPICAL TYPE A ELEVATIONS

Project Information

  • Client: EN VIRO TEC GENERAL CONTRACTING LTD.
  • Project: Development Permit 102 Atkins Road, View Royal B.C.
  • Drawing Number: 7548
  • Scale: 1/4" = 1'0"
  • Drawn By: NS
  • Date: 25/1/16
Architectural drawing sheet showing four elevations—Front, Right Side, Rear, and Left Side—for a "Typical Type A" home at 102 Atkins Road.
Architectural drawing sheet showing four elevations—Front, Right Side, Rear, and Left Side—for a "Typical Type A" home at 102 Atkins Road.

1. Front Elevation

Scale: 1/4" = 1'-0"

Detailed view of the Front and Right Side architectural elevations for a Typical Type A home.
Detailed view of the Front and Right Side architectural elevations for a Typical Type A home.
  • Midpoint Of Roof: 34.46m
  • Top Of Plate: 32.18m
  • Upper Floor Elevation (U.F.E.): 30.41m
  • Main Floor Elevation (M.F.E.): 27.67m
  • Average Finished Grade: 27.37m

Labels and Materials:

  • Decorative knee brace
  • Board and batten siding
  • 2x8 fascia trim
  • Pre-finished metal roofing
  • 1x4 door and window trim
  • Concrete fibre panel siding
  • Concrete fibre lap siding
  • Pre-finished aluminum gutter
  • 1x4 corner trim
  • Pre-manufactured stone veneer
  • 12x12 framed columns
    Close-up detail of building siding and 12x12 framed columns
    Close-up detail of building siding and 12x12 framed columns

2. Right Side Elevation

Scale: 1/4" = 1'-0"

  • Building Height: 7.07 m

Labels and Materials:

  • Laminated asphalt shingles
  • 1x4 corner trim
  • Board and batten siding
  • Concrete fibre panel siding
  • Pre-finished metal roofing
  • Concrete fibre lap siding
  • Pre-finished aluminum gutter
  • Metal flashing on 2x12 fascia
  • 12x12 framed columns
  • Decorative knee brace

3. Rear Elevation

Scale: 1/4" = 1'-0"

  • Midpoint Of Roof: 34.46m
  • Top Of Plate: 32.18m
  • U.F.E.: 30.41m
  • M.F.E.: 27.47m
  • Average Finished Grade: 27.37m

Labels and Materials:

  • Laminated asphalt shingles
  • 2x8 fascia trim
  • Pre-finished aluminum gutter
  • 1x4 door and window trim
  • Board and batten siding
  • 1x4 corner trim
  • Concrete fibre lap siding
  • Metal flashing on 2x12 fascia

4. Left Side Elevation

Scale: 1/4" = 1'-0"

Labels and Materials:

  • Laminated asphalt shingles
  • Pre-finished aluminum gutter
  • Concrete fibre panel siding
  • Concrete fibre lap siding
  • Metal flashing on 2x12 fascia
  • 1x4 corner trim
  • 12x12 framed columns
  • Pre-manufactured stone veneer
  • Board and batten siding
Page 34
