Council Meeting/Documents/Attachment 11 - Typical Type B Elevations
Appendix

Attachment 11 - Typical Type B Elevations

February 2, 2016Page 351 section

Detailed drawings of the front, rear, and side elevations for Type B buildings.

8.1.a Development Permit No. 2015/12 - 102 Atkins Road
Date: 25/1/16

TYPICAL TYPE B ELEVATIONS

Architectural elevation drawings for typical Type B homes at 102 Atkins Road, featuring front, right side, rear, and left side views with material annotations and height markers.
Architectural elevation drawings for typical Type B homes at 102 Atkins Road, featuring front, right side, rear, and left side views with material annotations and height markers.

Drawing Information

  • Project: 102 Atkins Road, View Royal B.C.
  • Drawing #: 7548
  • Scale: 1/4" = 1'-0"
  • Drawn by: NS
  • Date: 25/1/16

Elevation Views

  1. Front Elevation (Scale: 1/4" = 1'-0")
  2. Right Side Elevation (Scale: 1/4" = 1'-0")
  3. Rear Elevation (Scale: 1/4" = 1'-0")
  4. Left Side Elevation (Scale: 1/4" = 1'-0")

Architectural Materials and Features

The drawings identify the following materials and construction details:

  • Laminated asphalt shingles
  • 2x10 fascia trim
  • Conc. fibre panel siding
  • Pre-fin. metal roofing
  • 1x4 door and window trim
  • 1x4 corner trim
  • Conc. fibre lap siding
  • Pre-fin. alumin. gutter
  • Extruded alumin. corner trim
  • Pre-manuf. stone veneer
  • Custom porch trim
  • Metal flashing on 2x12 fascia

Height Reference Points

  • Midpoint of Roof
  • Top of Plate
  • U.F.E.
  • M.F.E.
  • Ave. Finished Grade
Page 35
