B.C. LAND SURVEYOR’S SITE PLAN - 2700 Herbate Road

B.C. LAND SURVEYOR'S SITE PLAN OF: LOT 3, SECTION 3, HIGHLAND DISTRICT, PLAN VIS5236

SCALE 1 : 150
All distances are in metres.
The intended plot size of this plan is 280mm by 432mm. Scale is correct at which size plotted at a scale of 1:150.
NOTE 1: Elevations are based on a local datum and are referenced to the Iron Post at the northwest corner of elevation 32.17 metres.

All rights reserved. No person may copy, reproduce, transmit or alter this document in whole or in part without the written consent of BCD Inc.
This record was prepared for the exclusive use of our client, Brad Johnson.
This document is intended for use as a topographic plan. It is based on Land Title Office records, and was not improved by a boundary survey.
BCD Inc. accepts no responsibility for or liability for any changes that may be suffered by a third party as a result of any decisions made or actions taken based on this document.

Strata Lot A: Contains No. 2780 Dwelling, a garage, a gravel path, and a concrete apron.
Strata Lot B: Contains an existing garage and a designated "Area of Addition."
Access: Common Property Access and an asphalt driveway.
Adjacent Features: Herbate Road, McKenzie Lane, Plan 29610, and REM. A.
Key Plan Inset:

FILE: 11208 - M114
Surveyor: Real Canada Land Surveyor
Address: 4101 - 3550 Douglas Street, Victoria, B.C. V8X 3P3
Contact: ph: 250-884-0226 fx: 388-3000, email@realcanada.ca
Certification: Certified Correct on the 26th day of April, 2011, by Bradley Cunnin, BCLS.
