Partial Site Plan & Project Data - 2700 Herbate Road
February 16, 2016Page 241 section
Architectural drawing showing the proposed area of addition and project statistical data.
February 11, 2016Suite addition area: 93.11 m²
PROPOSED
PROJECT DATA
| Description | Data |
|---|---|
| LEGAL DESCRIPTION | LOT 3, SECTION 3, HIGH-LAND DISTRICT, PLAN VIS5236 |
| ZONING | A-3 |
| LOT SIZE | 4,670.00 m² |
| BUILDING AREA | EXISTING HOUSE: 278.89 m² SUITE ADDITION: 93.11 m² TOTAL: 372.00 m² |
| LOT COVERAGE (974.00 m² MAX) | 372.00 m² |
| SETBACKS | FRONT: 82.77 m REAR: 34.78 m INTERIOR, EAST: 4.40 m INTERIOR, WEST: 33.11 m |
| AVERAGE GRADE | 55.34 m |
| BUILDING HEIGHT | 4.13 m |
PARTIAL SITE PLAN
Site Plan Annotations:
- LINE OF EXTERIOR WALLS BELOW
- LINE OF EXISTING SEPTIC FIELD
- EXISTING HOUSE: 278.89 m²
- NEW CONSTRUCTION
- EXISTING CONSTRUCTION
- PROPOSED ADDITION TO EXISTING HOUSE: 93.11 m²
Detail view of the proposed addition to the existing house.
- 14'-3 1/2" [4.4m] SIDEYARD SETBACK
- AREA OF GARAGE TO BE REMOVED
- EXISTING ASPHALT DRIVEWAY
- EXISTING PROPERTY LINE
- NEW HALLWAY CONNECTION TO EXISTING GARAGE FOR PROPOSED SUITE
- LINE OF EXTERIOR WALLS BELOW
- LINE OF EXISTING CONCRETE APRON
- 13'-1 1/2" [4.00 m]
PROJECT INFORMATION
| Detail | Information |
|---|---|
| Address | #4 - 7855 East Saanich Rd., Saanichton V8M 2B4 |
| Phone | 250-656-2224 |
| Fax | 250-656-2279 |
| info@finlaysonbonet.ca | |
| Checked | KS |
| Drawn | RJC |
| Scale | 1 : 200 |
| Date | FEBRUARY 11, 2016 |
| Project Name | 2700 HERBATE ROAD, VIEW ROYAL, BC |
| Project No. | 15040 |
| Drawing Title | PARTIAL SITE PLAN & PROJECT DATA |
| Drawing No. | A0.00 |
