SOUTH BUILDING SECTIONS & SITE DETAILS (Attachment 4 DP1.1)

Eagle Creek Village Phase 2

SHEET NOTES

A. ALL SITE INFORMATION TAKEN FROM INFORMATION PROVIDED BY MCELHANNEY ASSOCIATES LAND SURVEYING LTD. GENERAL CONTRACTOR TO CONSULT WITH CIVIL ENGINEER PRIOR TO ESTABLISHING PROPERTY LINE, DATUM AND BUILDING LOCATION.

B. GENERAL CONTRACTOR TO COORDINATE ALL UTILITY LINE CONNECTIONS WITH TOWN OF VIEW ROYAL.

C. REFER TO LANDSCAPE ARCHITECT'S DRAWINGS AND SPECS. FOR ALL LANDSCAPING, SITE GRADING, SITE DRAINAGE AND STORM WATER MANAGEMENT.

D. BUILDING OUTLINE REPRESENTS EDGE OF SLAB MAIN LEVEL. ALL DIMENSIONS SHOWN ARE TO GRID LINES.

E. REFER TO CIVIL ENGINEER'S DRAWINGS AND SPECS. FOR ALL EARTHWORKS, ROADWORK, RETAINING WALLS & DRAINAGE.

F. REFER TO ELECTRICAL DRAWING FOR ALL UTILITY CONNECTIONS.

G. GENERAL CONTRACTOR TO PATCH AND MAKE GOOD ALL LANDSCAPING, WALKWAYS, AND ROADWAYS DAMAGED DURING CONSTRUCTION.

H. THIS PLAN IS ISSUED FOR THE PURPOSE OF POSITIONING THE BUILDING IN RELATION TO THE SITE. REFER TO ENGINEER'S AND LANDSCAPE ARCHITECT'S DRAWINGS FOR ALL OTHER SITE INFORMATION.

I. UNLESS OTHERWISE NOTED ALL DIMENSIONS TO THE PROPERTY LINE ARE PERPENDICULAR TO THE PROPERTY LINE.

J. REFER TO CIVIL DRAWINGS FOR FIRE TRUCK ACCESS.

K. BARRIER-FREE ACCESS, CURB CUTS AND RAMPS TO CONFORM TO BC BUILDING CODE.

L. CROSSWALKS AND HANDICAP PARKING SYMBOLS TO BE PAINTED. REFER TO LANDSCAPE ARCHITECT'S DRAWINGS.

ISSUED

SOUTH BUILDING SECTIONS & SITE DETAILS

1 SITE SECTION (DP1.1)

• Scale: 1:200
• Building Levels:
  • T.O. PARAPET: 117.37
  • U.S. OF TRUSS: 115.83
  • T.O. FOURTH FLOOR: 112.53
  • T.O. THIRD FLOOR: 108.67
  • T.O. SECOND FLOOR: 105.51
  • T.O. MAIN FLOOR SLAB: 102.35
  • T.O. PARKADE SLAB: 100.00 (GEO. 27.0m)
• Features: Access road, reinforced engineered boulder wall, bermed up boulders with planting.

2 SITE SECTION (DP1.1)

• Scale: 1:200
• Features: South Building relationship to Eagle Creek Village Phase 1 Building 2, parkade access driveway, and storage lockers.

3 SITE SECTION (DP1.1)

• Scale: 1:100
• Features: Detail of reinforced engineered boulder wall, access road at GEO. 23.3m, and building footings at U.S. OF FOOTING 95.30 (GEO. 22.3m).

4 SITE SECTION (DP1.1)

• Scale: 1:100
• Features: Detail of parkade access to North Building, storage lockers, trellis planting within rock garden, and concrete pathway.

5 ALLAN BLOCK RETAINING WALL TYP. SECTION (DP1.1)

• Scale: 1:50
• Finished Grades:
  • T.O. PHASE 2 FINISHED GRADE: 38.35
  • T.O. PHASE 1 FINISHED GRADE: 22.30
• Features: Reinforced engineered Allan Block wall.

Project Information:

• Company: OMICRON ARCHITECTURE ENGINEERING LTD.
• Project Number: 11 14 032
• Drawn: RI
• Checked: IM
• Sheet Number: DP1.1
