SOUTH BUILDING PARKADE PLAN (Attachment 5 DP2.0)

October 18, 2016Page 801 section

Technical drawing of the underground parking level including stall numbering and storage areas.

33 stalls in the south building parkadeDrawing Number: DP2.0

Eagle Creek Village Phase 2

South Building Parkade Plan

Floor plan diagram for the South Building Parkade at Eagle Creek Village Phase 2, showing 33 parking stalls, 42 storage lockers, electrical room, mechanical room, and lobby.
Floor plan diagram for the South Building Parkade at Eagle Creek Village Phase 2, showing 33 parking stalls, 42 storage lockers, electrical room, mechanical room, and lobby.

Drawing Details

  • Sheet Number: DP2.0
  • Project Number: 11 14 032
  • Scale: 1:100
  • Drawn by: RI
  • Checked by: IM
  • Status: NOT FOR CONSTRUCTION

Issue Summary

# Date Remarks
1 22 SEP 2013 ISSUED FOR DP
2 10 JUL 2015 RE-ISSUED FOR DP
3 20 MAY 2016 RE-ISSUED FOR DP

Parkade Plan Specifications

  • Level: Mainfloor / Parking Floor
  • Total Area: 13,018 SQ.FT. [1209 M²]
  • Parking Stalls: 33 total stalls (including stalls designated for "SMALL CAR")
  • Overhead Clearance: Provide minimum 2.1m overhead clearance.

Rooms and Areas

  • ELEC. ROOM
  • MECH. ROOM
  • STORAGE (multiple locations)
  • STORAGE LOCKERS (labeled 1 through 42)
  • LOBBY
  • MAIL
  • GARAGE & RECYCLING ROOM
  • EXIT areas

Grid Reference System

  • Horizontal Axis: A, B, C, D, E, G, H, J, K, L, M, N, N'
  • Vertical Axis: 1, 1', 2, 3, 4, 5, 6
