Council Meeting/Documents/SOUTH BUILDING FOURTH FLOOR PLAN (Attachment 8 DP2.3)
Appendix

SOUTH BUILDING FOURTH FLOOR PLAN (Attachment 8 DP2.3)

October 18, 2016Page 831 section

Layout of the residential units on the building's top level.

10 units on this floorDrawing Number: DP2.3

Eagle Creek Village Phase 2

SOUTH BUILDING FOURTH FLOOR PLAN

Architectural floor plan for the fourth floor of the South Building, illustrating the layout of unit types E2i, Ci, C2, G, Ci, Ci, F, C1, and D1i, along with corridors, stairwells, and balconies.
Architectural floor plan for the fourth floor of the South Building, illustrating the layout of unit types E2i, Ci, C2, G, Ci, Ci, F, C1, and D1i, along with corridors, stairwells, and balconies.

FORTH FLOOR PLAN

  • UNIT Ci (3 UNITS) 875X3 = 2,625 SQ.FT [244m²]

  • UNIT C1 (1 UNIT) 924 SQ.FT [86m²]

  • UNIT C2 (1 UNIT) 1190 SQ.FT [111m²]

  • UNIT D1i (2 UNITS) 998X2 = 1,996 SQ.FT [186m²]

  • UNIT E2i (1 UNIT) 1103 SQ.FT [103m²]

  • UNIT F (1 UNIT) 530 SQ.FT [49m²]

  • UNIT G (1 UNIT) 704 SQ.FT [65m²]

  • TOTAL 10 UNITS PER FLOOR 9,072 SQ.FT [843m²]

  • CORRIDOR / ELEVATOR AREA 1,297 SQ.FT [120m²]

  • 4TH FLOOR PLANS 10,369 SQ.FT [963m²]

  • (10,369 SQ. FT [963m²] TO EXTERIOR OF SHEATHING)

ISSUED

No. Date Remarks
P 22 MAY 2013 ISSUED FOR DP
1 25 JUL 2013 REISSUED FOR DP
2 25 SEPT 2013 REISSUED FOR DP

OMICRON ARCHITECTURE ENGINEERING LTD.

  • Drawn: RI
  • Checked: IM
  • Project Number: 11 14 032
  • Drawing Number: DP2.3
Page 83
