LARGE SCALE UNIT PLANS - A, B, C1 (Attachment 10 DP2.6)

Eagle Creek Village Phase 2

LARGE SCALE UNIT PLANS

UNIT A - 641 SQ. FT (59 SQ. M.)

• Master (King): 10'3" x 11'6"
• W.I.C.
• Bath
• Laundry (W/D)
• Kitchen: 13'5" x 8'3"
• Living/Dining: 13'4" x 15'6"
• Balcony: 13' x 6'
• Entry

UNIT B - 864 SQ. FT. (80.29 SQ. M)

• Master (King): 10'3" x 12'2"
• W.I.C.
• Bath
• Laundry (W/D)
• Kitchen: 8'4" x 12'8"
• Storage
• Living/Dining: 13'7" x 15'11"
• Bedroom (Queen): 12'2" x 11'11"
• Closet
• Balcony: 13' x 6'
• Entry

UNIT C1 - 875 SQ. FT. (81.31 SQ. M.)

• Master (King): 10'0" x 11'6"
• Bath
• Kitchen: 12'9" x 8'2"
• Dining: 11'11" x 7'4"
• Living: 11'1" x 9'3"
• Master (King): 10' x 12'
• W.I.C.
• Bath
• Balcony: 10' x 7'

UNIT C1 ADAPTABLE - 875 SQ. FT. (81.31 SQ. M.)

• Master (King): 10'0" x 11'6"
• Bath
• Kitchen: 12'9" x 8'2"
• Dining: 11'11" x 7'4"
• Living: 11'1" x 9'3"
• Master (Queen): 10' x 12'
• W.I.C.: 8'1" x 6'2"
• Bath
• Balcony: 10' x 7'
• Note: Plan includes designated 5'-0" turning radii for adaptability.
