LARGE SCALE UNIT PLANS - C-1, C-2, D1i, D3i (Attachment 11 DP2.7)
Detailed interior layouts for various two-bedroom and specialized unit types.
Eagle Creek Village Phase 2
LARGE SCALE UNIT PLANS
UNIT C-1 - 924 SQ. FT. (85.87 SQ. M.)
- Living/Dining: 12'4" x 16'7"
- Kitchen: 8'2" x 9'2"
- Master (King) Bedroom 1: 10'3" x 11'6" with Walk-in Closet (W.I.C.) and Ensuite Bathroom
- Master (King) Bedroom 2: 9'8" x 11'2" with Walk-in Closet (W.I.C.) and Ensuite Bathroom
- Balcony: 13' x 8'
- Additional features: Coats closet, shelving units
UNIT C-2 - 1190 SQ. FT. (111 SQ. M.)
- Living/Dining: 12'7" x 18'5"
- Kitchen: 12'7" x 9'2"
- Master (King) Bedroom: 12'4" x 12' with Walk-in Closet (W.I.C.) and Ensuite Bathroom
- Bedroom (Queen) 1: 10' x 13'6"
- Bedroom (Queen) 2: 10'2" x 11'11" with Closet
- Additional features: Coats closet, additional hallway closet, second full bathroom, balcony
UNIT D11 - 998 SQ. FT. (92.75 SQ. M.)
- Living Area: 11'10" x 12'4"
- Dining Area: 8'10" x 12'4"
- Kitchen: 12'7" x 9'2"
- Master (King) Bedroom: 12' x 10'8" with Walk-in Closet (W.I.C.), shelving, and Ensuite Bathroom
- Bedroom: 10'1" x 11'4"
- Balcony: 6' x 12'
- Additional features: Storage room, pantry with shelves
UNIT D31 - 1083 SQ. FT. (100.65 SQ. M.)
- Living / Dining: 20'5" x 12'4"
- Kitchen: 10'7" x 9'2"
- Master Bedroom: 13'2" x 11'3" with Walk-in Closet (W.I.C.) and Ensuite Bathroom
- Bedroom: 8'8" x 14'4" with Walk-in Closet (W.I.C.)
- Balcony: 8' x 12'8"
- Storage: 5'6" x 5'
- Additional features: Second full bathroom, coats closet
Revision Schedule
| # | Date | Remarks |
|---|---|---|
| 1 | 03 SEPT 2014 | ISSUED FOR DP |
| 2 | 20 JUL 2015 | RE-ISSUED FOR DP |
| 3 | 30 SEPT 2016 | RE-ISSUED FOR DP |
Project Information
- Consultant: OMICRON (833 - 4th Avenue SW, Calgary, AB T2P 3T5)
- Project Name: Eagle Creek Village Phase 2
- Project Number: 11 14 032
- Date: 30 SEPT 2016
- Drawn By: RI
- Checked By: IM
- Sheet Name: LARGE SCALE UNIT PLANS
- Sheet Number: DP2.7
