LARGE SCALE UNIT PLANS - E2i, F, F1, G (Attachment 12 DP2.8)

October 18, 2016Page 871 section

Detailed interior layouts for studio and large corner units.

Unit F1: 483 SQ FTUnit E2i: 1103 SQ FT

LARGE SCALE UNIT PLANS

Eagle Creek Village Phase 2

Architectural floor plans for Unit E2i, Unit F, Unit F1, and Unit G, including room labels and dimensions.
Architectural floor plans for Unit E2i, Unit F, Unit F1, and Unit G, including room labels and dimensions.

Issued Revisions

# Date Remarks
31 MAY 2013 APPLIED FOR DP
1 22 JUL 2014 REVISED FOR DP
2 22 SEPT 2014 REVISED FOR DP

Unit Specifications

UNIT E2i

  • Total Area: 1103 SQ. FT. (102.5 SQ. M.)
  • Room Dimensions:
    • Balcony: 8' x 12'8"
    • Master: 11' x 16'7"
    • Living / Dining: 20'5" x 13'4"
    • Kitchen: 10'7" x 9'2"
    • Bedroom: 9' x 11'6"
    • W.I.C.: 5' x 8'8"
    • Storage: 5' x 5'8"

UNIT F

  • Total Area: 530 SQ. FT. (49 SQ. M.)
  • Room Dimensions:
    • Bedroom (Queen): 10' x 9'8"
    • Living: 12'6" x 9'7"
    • Kitchen: 8'10" x 7'1"

UNIT F1

  • Total Area: 483 SQ. FT. (45 SQ. M.)
  • Room Dimensions:
    • W.I.C.: 5'4" x 5'6"
    • Murphy Bed: 8'8" x 9'8"
    • Living: 7'6" x 7'5"
    • Kitchen: 8'5" x 7'7"

UNIT G

  • Total Area: 704 SQ. FT. (65.4 SQ. M.)
  • Room Dimensions:
    • Living / Dining: 11'8" x 12'9"
    • Balcony: 8' x 12'8"
    • Kitchen: 8'10" x 9'5"
    • Master (King): 9'5" x 12'8"

Project Information

  • Project Number: 11 14 032
  • Sheet Number: DP2.8
Page 87
