SOUTH BUILDING EXTERIOR ELEVATIONS - SOUTH & EAST (Attachment 13 DP3.1)
Visual representation of the building's facade materials and height from the south and east.
SOUTH BUILDING EXTERIOR ELEVATIONS
1 SOUTH ELEVATION
SCALE: 1:100
Elevation Levels:
- T.O. PARAPET: 117.37
- U.S. OF TRUSS: 115.63
- T.O. FOURTH FLOOR: 112.83
- T.O. THIRD FLOOR: 109.87
- T.O. SECOND FLOOR: 106.91
- T.O. MAIN FLOOR SLAB: 103.35
- T.O. PARKADE FLOOR: 100.00
2 EAST ELEVATION
SCALE: 1:100
3 TYP. ROOFTOP SCREENING ELEVATION
SCALE: 1:100
SHEET NOTES
A. ALL ELEVATIONS ARE FROM DATUM ELEVATION PARKING LEVEL - 100.00 B. VENTS AND OTHER VISIBLE EXTERIOR FINISH ELEMENTS NOT FULLY DETAILED OR DETAILED ON THIS PLANS SHALL BE FINISHED TO THE SAME COLOUR AS THE ADJOINING SURFACE, UNLESS NOTED OTHERWISE BY ARCHITECT ON MATERIALS. C. REFER TO ELECTRICAL & LANDSCAPE DRAWINGS FOR EXTERIOR LIGHTING. D. SEE KEY NOTES FOR FINISH MATERIALS AND COLORS. E. LANDSCAPE ARCHITECT'S DRAWINGS SHALL TAKE PRECEDENCE OVER ARCHITECT ALL FINISH GRADE ELEVATIONS AND PROPERTIES. F. ALL EXPOSED DOWN SPOUTS, FLASHINGS, VENTS, ELECTRICAL CONDUITS, ETC. SHALL BE PRE-FINISHED TO MATCH THE COLOR OF THE ADJOINING FINISHES / WALL. G. ALL DOORS AND WINDOWS EXPOSED TO AMBIENT CONDITIONS, UNLESS NOTED OTHERWISE ON SCHEDULES, SHALL BE THERMALLY BROKEN AND OPERABLE SASH WEATHERSTRIPPED TO LIMIT AIR INFILTRATION. H. ALL EXPOSED WOOD ELEMENTS SHOWN TO BE PRESSURE TREATED. I. ALL CEMENT BOARD SIDING (HARDIE BOARD) BUTT JOINTS BACKED WITH 30 GAUGE PREFINISHED METAL FLASHING. J. PROVIDE PREFINISHED METAL FLASHING AT ALL ROOF PANEL JOINTS.
KEYNOTE LEGEND
- CEMENTITIOUS SIDING - BOARD & BATTEN SIDING, COLOUR: JAMES HARDIE 'MONTEREY TAUPE'
- CEMENTITIOUS LAP SIDING TYPE 2 - 4" EXPOSURE, WOOD GRAIN COLOUR: JAMES HARDIE 'MONTEREY TAUPE'
- CULTURED STONE VENEER, COLOUR: 'COUNTRY LEDGESTONE'
- ENTRY CANOPY - EXPRESSED TIMBER CONSTRUCTION W/ WOOD GRAIN TEXTURE FINISH.
- RESERVED
- CEMENTITIOUS TRIM BOARD 19 x 140 EXPOSED TO VIEW, WOOD GRAIN TEXTURE, COLOUR TO MATCH JAMES HARDIE ARCTIC WHITE
- CEMENTITIOUS TRIM BOARD 19 x 285 CEDAR OR WOOD GRAIN TEXTURE, COLOUR: BLACK
- PARKADE EXHAUST LOUVER
- MANUFACTURED STONE LINTEL
- STRUCTURAL COLUMN CLAD W/ CEMENTITIOUS TRIM BOARD, COLOUR: BLACK
- OVERHEAD SECURITY GRILLE
- PREFINISHED METAL FLASHING CAP, COLOUR: BLACK
- ENAMELED METAL DOOR
- WOOD OR REPLICA WOOD CLADDING
- PVC FRAME WINDOW, FRAME COLOUR: BLACK
- ALUMINUM SLIDING DOOR
- ALUMINUM CLEAR GLASS DOOR, FRAME COLOUR: CLEAR ANODIZED
- INSULATED METAL DOOR
- POWDERCOATED ALUMINUM GUARDRAIL, COLOUR: BLACK
- ALUMINUM WINDOW, FRAME COLOUR: BLACK
- CONCRETE, COLOURLESS ELASTOMERIC COATING SYSTEM. AT ALL WALLS AT GRADE AND PARKADE EXTERIOR WALLS. FINISH GRADE / PAVING TO SLOPE AWAY FROM BUILDING.
- BALCONY EDGE FLASHING, COLOUR: BLACK
- CANOPY SOFFIT - WOOD OR REPLICA WOOD
- TRELLIS PLANTING WITHIN ROCK GARDEN - SEE SITE SECTION DETAILS
- FIRE DEPARTMENT CONNECTION
- ENTERPHONE
- CEMENTITIOUS SHINGLE SIDING TYPE 3, COLOUR TO MATCH JAMES HARDIE 'NIGHT GREY'
- PARKADE ROOF
ISSUED
| Date | Remarks |
|---|---|
| 07 SEPT 2015 | ISSUED FOR DP |
| 11 JUL 2016 | REISSUED FOR DP |
| 20 SEPT 2016 | REISSUED FOR DP |
PROJECT INFORMATION
- Project Name: Eagle Creek Village Phase 2
- Project Number: 11 14 032
- Drawn: RJ
- Checked: IM
- Sheet Number: DP3.1
