SOUTH BUILDING EXTERIOR ELEVATIONS - NORTH & WEST (Attachment 14 DP3.2)
Visual representation of the building's facade from the north and west sides.
P85
South Building Exterior Elevations
North Elevation
Scale: 1:100
| Level Mark | Elevation |
|---|---|
| T.O. PARAPET | 117.37 |
| U.S. OF TRUSS | 115.63 |
| T.O. FOURTH FLOOR | 113.83 |
| T.O. THIRD FLOOR | 109.67 |
| T.O. SECOND FLOOR | 105.51 |
| T.O. MAIN FLOOR SLAB | 102.35 |
| T.O. PARADE FLOOR | 100.00 |
West Elevation
Scale: 1:100
Sheet Notes
A. ALL ELEVATIONS ARE FROM DATUM ELEVATION PARADE LEVEL = 100.00. B. SOFFITS AND ANY OTHER VISIBLE EXTERIOR FINISH ELEMENTS NOT SPECIFICALLY INDICATED IN THE ELEVATIONS SHALL BE FINISHED IN THE SAME CHARACTER AS THE MAJOR CONDITIONS. REFER TO WALL SECTIONS & DETAILS FOR MATERIALS. C. REFER TO ELECTRICAL & LANDSCAPE DRAWINGS FOR EXTERIOR LIGHTING. D. SEE ID NOTES FOR FINISH MATERIALS AND COLORS. E. LANDSCAPE ARCHITECT'S DRAWINGS SHALL TAKE PRECEDENCE IN MATTERS OF FINISH GRADE ELEVATIONS AND REVEAL. F. ALL GUTTERS, DOWN SPOUTS, FLASHINGS, VENTS, EXHAUSTS, SCREENS ETC. SHALL BE PRE-FINISHED TO MATCH THE COLOR OF THE ADJACENT SURFACE, U.O.N. G. ALL DOORS AND WINDOWS EXPOSED TO AMBIENT CONDITIONS (OFFICE AND RE-PURPOSED SPACE) SHALL BE GASKETED, WEATHER STRIPPED OR OTHERWISE TREATED TO LIMIT AIR INFILTRATION. H. ALL EXPOSED WOOD ELEMENTS SHOWN TO BE PRESSURE TREATED. I. ALL FIBER-CEMENT SIDING (HARDIE BOARD) BUTT JOINTS SHALL BE FILLED WITH COLOUR MATCHING CAULK. J. PROVIDE PREFINISHED METAL FLASHING AT ALL ROOF/WALL JOINTS.
Keynote Legend
- CEMENTITIOUS BOARD & BATTEN SIDING, COLOUR: JAMES HARDIE 'MONTEREY TAUPE'.
- HORIZONTAL CEMENTITIOUS LAP SIDING 150mm EXPOSURE, COLOUR: JAMES HARDIE 'MONTEREY TAUPE'.
- CULTURED STONE VENEER, COLOUR: 'CHARCOAL' MIST LEDGESTONE.
- CEMENTITIOUS LAP SIDING WITH TIMBER STRUCTURE W/ WOOD GRAIN TEXTURE (RED).
- RESERVED.
- CEMENTITIOUS TRIM BOARD 19 x 140 (COLOUR: JAMES HARDIE 'MONTEREY TAUPE').
- CEMENTITIOUS TRIM BOARD 19 x 235 (COLOUR: JAMES HARDIE 'MONTEREY TAUPE').
- RESERVED.
- MANUFACTURED STONE LINTEL.
- STRUCTURAL COLUMN CLAD W/ CEMENTITIOUS TRIM BOARD, COLOUR: BLACK.
- OVERHEAD SECURITY GRILLE.
- PREFINISHED METAL FLASHING CAP, COLOUR: BLACK.
- OVERHEAD METAL DOOR.
- WOOD OR REPLICA WOOD CLADDING.
- PVC FRAME WINDOW, FRAME COLOUR: SAND.
- GLASS PATIO DOOR.
- ALUMINUM CLEAR GLASS DOOR, FRAME FINISH/COLOUR: BLACK.
- INSULATED METAL DOOR.
- PICKET-STYLE ALUMINUM GUARDRAIL, COLOUR: BLACK.
- ALUMINUM RAILING, FRAME COLOUR: CLEAR ANODIZED.
- CONCRETE PARAPET, OVER COATING C/W CAST IN PLACE REVEALS AT SPACING INDICATED, U.O.N.
- FINISH GRADE/PAVING TO SLOPE AWAY FROM BUILDING.
- BALCONY EDGE FLASHING, COLOUR: BLACK.
- CANOPY SOFFIT - WOOD OR REPLICA WOOD.
- CONCRETE PLANTING RETAINING GARDEN - SEE SITE SECTION DETAILS.
- FIRE DEPARTMENT CONNECTION.
- ENTERPHONE.
- CEMENTITIOUS SHINGLE SIDING TYPE 2, COLOUR TO MATCH JAMES HARDIE 'NIGHT GRAY'.
- PARADE ROOF.
Project Details
- Project Name: Eagle Creek Village Phase 2
- Project Number: 11 14 032
- Sheet Number: DP3.2
- Drawn: RI
- Checked: IM
