FIRE TRUCK TURNING TEMPLATE (Attachment 23)

EAGLE CREEK VILLAGE - PHASE 2 FIRE TRUCK TURNING TEMPLATE

Site plan for Eagle Creek Village Phase 2 showing fire truck turning templates around the North Building, South Building, and Building 5.

High-contrast site plan detailing the fire truck turning paths and building layouts for Phase 2.

Project Information

Project: EAGLE CREEK VILLAGE OMICRON DEVELOPMENT INC.
Title: FIRE TRUCK TURNING TEMPLATE PHASE 2
Consultant: WESTBROOK Consulting Ltd.
Address: #115 - 866 Goldstream Ave., Victoria, BC V9B 0J3
Telephone: 250-391-8582
Fax: 250-391-8593
Westbrook Project No.: 2623
Date: 2016.05.20
Figure: 1
Sheet: 1 of 1

Revisions

No.	Description	Date	By	Chk.
1	REVISED ACCESS ALIGNMENT AND PARKING	2016.03.31	PC	ELH
2	REVISED PER TOWN COMMENTS	2016.05.11	PC	ELH

Legend - Proposed services shown bold

Symbol	Description	Symbol	Description
—— W ——	WATER	⬚	HANDHOLE
—— S ——	SEWER	⊙	CLEANOUT
—— D ——	DRAIN	▅	CATCHBASIN
————	NATURAL GRADE	🚩	ROAD SIGN
======	CULVERT	⦾	HYDRANT
⊓	HEADWALL	⧇	VALVE
—— G ——	GAS	⊠	METER
—— H ——	HYDRO	⧓	REDUCER
—— T ——	TEL	◈	MONUMENT
.......	SIDEWALK	•	LOT PIN
_______	CURB/CURB & GUTTER	+	LEAD PLUG
— · — ·	PROPERTY LINE
~~~~~~	BUSHLINE
🌲	TREE
[Graphic]	EXISTING S/W UTIL
[Graphic]	PROPOSED L/S UTIL
¤	LIGHT STANDARD
⌾	POWER POLE
┥	ANCHOR

Location Plan

Site Address: 33 HELMCKEN ROAD Legal Description: LOT A, SECTIONS 8 & 102, LAKE & ESQUIMALT DISTRICTS, PLAN EPP23184.

The location plan shows the site's proximity to:

Helmcken Road
Watkiss Way
Burnside Road West
V.G. General Hospital

Fire Truck Specifications (TOVR)

Vehicle: TOVR
Width: 2.60m
Track: 2.60m
Overall Length: 11.23m
Wheelbase: 5.86m
Front Overhang: 2.44m
Lock to Lock Time: 6.00s
Steering Angle: 45.0°

General Notes

THE LOCATION AND ELEVATION OF EXISTING UNDERGROUND SERVICES ON THIS DRAWING MAY NOT BE ACCURATE OR COMPLETE. HORIZONTAL AND VERTICAL LOCATIONS MUST BE CONFIRMED BY UTILITY COMPANIES AND THE CONTRACTOR PRIOR TO THE START OF ANY EXCAVATION.
