Appendix
LANDSCAPE CONCEPT - SUPPORTING IMAGES (Attachment 26 L3)
October 18, 2016Pages 101–1021 section
Visual precedents for site features like fencing, benches, and wall finishes.
Includes precedent images for Allan Block retaining walls and bike racks
Eagle Creek Village Phase 2
Landscape Concept - Supporting Images
Project Number: 1420 Sheet: L3 Location: Town of View Royal, British Columbia
Revision History
| No. | Date | Remarks |
|---|---|---|
| 1 | Sept 2/15 | DP Submission |
| 2 | Dec 14/15 | Landscape Revised |
| 3 | Jan 29/16 | Landscape Revised |
| 4 | Feb 18/16 | Landscape Revised |
| 5 | July 6/16 | Landscape Revised |
| 6 | Sept 29/16 | DP Resubmission |
Landscape Precedent Images
Precedent Image for Bench - 'Equiparo' Style 1930
Precedent Images for Cable Screens on Walls for Vines
Built Retaining Walls Between Phase I and II
Specifications:
- Allan Block, manufactured by Expocrete.
- Size 8" high x 18" long.
- Colour - "natural" (grey) concrete.
- Finish - "split face".
Landscape Details and Conceptual Sections
Planted Car/Bumper Overhang Detail (1:30)
- Car Bumper Overhang
- Ground Covers
- Planting Bed
Modular Retaining Walls Between Phase I & II (Conceptual) (1:30)
- YMCA Playground - Phase 1
- Property Line
Site Section: Transition Between Phase 1 and Phase 2
- Eagle Creek Village Phase 1
- Eagle Creek Village Phase 2
- Property Line
- Allan Block Wall Typ.
- Distance and Slope Varies. TBD.
- Parking
- Note: Landscape Concept Subject to Change Based on Final Grades of Native Material/Rock.
Page 2
Page 101–102
Document Images
(3)
Extracted from: 2016 10 18 Council Agenda - Pdf
