COLOUR BOARD (Attachment 28)

October 18, 2016Page 1041 section

A sample board showing the actual colors and textures of exterior building materials.

Includes James Hardie Monterey Taupe and Arctic White samplesGround floor concrete walls to be painted in earth tones

EAGLE CREEK VILLAGE PHASE II

Attachment 28

Material sample board for Eagle Creek Village Phase II featuring an architectural rendering of the building, various siding samples in grey, beige, and white, dark grey stone veneer samples, earth-toned paint swatches, and a large reddish-brown panel.
Material sample board for Eagle Creek Village Phase II featuring an architectural rendering of the building, various siding samples in grey, beige, and white, dark grey stone veneer samples, earth-toned paint swatches, and a large reddish-brown panel.

Material Board Details:

  • Exterior Rendering: [Rendering of building titled "VIEW FROM ROAD"]
  • Siding Samples: Various textured siding panels in shades of grey, taupe, and white.
  • Stone Veneer: Two rectangular samples of dark grey textured stone veneer.
  • Cladding: Large reddish-brown panel noted as "OR REPLICA WOOD CLADDING".
  • Paint Specifications: Ground floor concrete walls to be painted in earth tones similar to one of the following:
Page 104
