Urban Ground Market Sign Illustrations

Signage Design Plan

Components and Dimensions

TO BE RETAINED

• Logo Graphic
  • Dimensions: 1.71 m width x 2.41 m height
  • Area: 4.12 m²
• "URBAN" Text
  • Dimensions: 2.68 m length x 0.74 m height
  • Area: 1.98 m²
• "GROUND" Text
  • Dimensions: 3.32 m length x 0.75 m height
  • Area: 2.49 m²

TO BE REMOVED

• Separator Bar
  • Dimensions: 0.21 m width x 1.63 m height
  • Area: .34 m²
• "MARKET" Text
  • Dimensions: 4.68 m length x 1.05 m height
  • Area: 4.91 m²

Area Summary

4.12 m² + 1.98 m² + 2.49 m² + .34 m² + 4.91 m² = 13.84 m² total area

Construction Details

LED Illuminated, aluminum, halo lit channel letters attached to raceway painted to match building. Faces and edges of letters painted to match customer approved logo colours.
