Appendix

Main Floor Plan

July 19, 2016Page 751 section

Architectural floor plan for the main residential level of the development.

8.1c Development Permit No. 2016/05 - 1950 Watkiss Way

Drawing A1.1

1950 WATKISS WAY, VIEW ROYAL BC

PRELIMINARY PLANS

Architectural drawing titled "MAIN FLOOR PLAN" for a development at 1950 Watkiss Way, featuring a U-shaped building footprint with residential units, common areas such as a lobby and bicycle storage, and an outdoor parking lot with numbered stalls.

Project Information

Project: 1950 WATKISS WAY, VIEW ROYAL BC
Architect: D'AMBROSIO ARCHITECTURE + URBANISM
Client: Denford Investments Inc.
Date: July 26, 2018
Project No: 1438
Scale: 1/8" = 1'-0"
Sheet Number: A1.1
Sheet Title: MAIN FLOOR PLAN

Site and Building Details

Permit Reference: Retaining Development Permit 2018/05
Building Level: FFL 22.0m (Lobby)
Interior Features:
- Lobby
- Mail Boxes
- Staff Room
- Bicycle Racks (multiple locations)
- Storage / Bicycle Racks
Site Features:
- Retaining Wall Height: 4' - 6" (North boundary)
- Retaining Wall Height: 1' - 6" (East boundary)
- Retaining Wall Height: 6' - 6" (East boundary)
- Retaining Wall Height: 6' (West boundary)
- Driveway Slopes: 6% slope, 6.7% slope, 6 1/2% slope

Parking Stall Information

Stall Number	Type	Dimensions
1	Standard	8.5' [2.60m] x 19.0' [5.80m]
13		5.6' [1.71m] (width)
14	Accessible	12.1' [3.70m] x 19.0' [5.80m]
23		7.9' [2.40m] (width)
33	Accessible	12.1' [3.69m] x 19.0' [5.80m]
35	Standard	8.5' [2.60m] x 19.0' [5.80m]
S (Multiple)	Small Car	15.7' [4.80m] (depth)

Key Dimensions and Site Markers

Drive Aisle Widths: 22.0' [6.71m], 24.0' [7.30m]
Setbacks/Distances: 19.7' [6.00m], 39.4' [12.00m], 23.3' [7.10m]
Site Markers: Iron Pin (multiple locations), True North and Project North indicators.

Page 75
