Roof Plan Drawing

July 19, 2016Page 781 section

Architectural plan showing the layout and mechanical screening on the building roof.

8.1c Development Permit No. 2016/05 - 1950 Watkiss Way
Drawing A1.4

Preliminary Plans: 1950 Watkiss Way, View Royal, BC

Development Permit: 2016/05 Client: Denford Investments Inc. Project No: 539 Date: July 8th 2016

Roof Plan

Architectural roof plan for 1950 Watkiss Way. The drawing shows an L-shaped building footprint with various shingled roof sections and a central area for mechanical units protected by 4' high screening. The plan is laid out on a coordinate grid labeled A through H vertically and 1 through 9 horizontally, with detailed dimensions for various roof segments.
Architectural roof plan for 1950 Watkiss Way. The drawing shows an L-shaped building footprint with various shingled roof sections and a central area for mechanical units protected by 4' high screening. The plan is laid out on a coordinate grid labeled A through H vertically and 1 through 9 horizontally, with detailed dimensions for various roof segments.

Sheet Number: A1.4

Page 78
Extracted from: 2016 07 19 Council Agenda - Pdf
