Council Meeting/Documents/Preliminary Elevations Drawing
Appendix

Preliminary Elevations Drawing

July 19, 2016Page 792 sections

Elevations from all cardinal directions showing building materials and logo placement.

8.1c Development Permit No. 2016/05 - 1950 Watkiss Way
Hardie Plank SidingAluminum Railing

EXTERIOR MATERIALS

CODE COLOR MATERIAL
1 8" HARDIE PLANK SIDING
2 NATURAL/IMITATION WOOD SIDING
3 HARDIE PANELS CEMENTITIOUS PANEL SIDING
4 HARDIE PANELS CEMENTITIOUS PANEL SIDING (WING WALLS)
5 NATURAL/CULTURED VENEER STONE
6 ALUMINUM STOREFRONT WINDOWS/DOORS AT MAIN FLOOR
7 VINYL WINDOWS
8 ALUMINUM RAILING
Architectural elevation drawings showing the South, North, East, and West views of the building at 1950 Watkiss Way, including material callouts and site grade measurements.
Architectural elevation drawings showing the South, North, East, and West views of the building at 1950 Watkiss Way, including material callouts and site grade measurements.
Page 79

PRELIMINARY ELEVATIONS - 1950 WATKISS WAY, VIEW ROYAL, BC

SOUTH ELEVATION

  • 33.39m Highest Point
  • 43.5' [13.24m]
  • 41.0' [12.49m]
  • 20.15m Average Finish Grade
  • 18m
  • 17m at property line
  • SIDEWALK
  • BUS STOP
  • LOGO (marked on two storefront locations)

NORTH ELEVATION

  • P.L (Property Line)

EAST ELEVATION

WEST ELEVATION

  • Grade markings: 24m, 23m, 22m, 21m, 20m, 19m, 18m, 17m
  • P.L (Property Line)

Project Information

  • Attachment: 11
  • Project: 1950 WATKISS WAY, VIEW ROYAL, BC
  • Date: JAN 18 2016
  • Scale: 1/8" = 1'-0"
  • Project No: 2011
  • Drawing No: A2.1
Page 79
