Tree Protection Fencing Technical Detail

July 19, 2016Page 951 section

Engineering standards for constructing tree protection barriers.

8.1c Development Permit No. 2016/05 - 1950 Watkiss Way
38 x 89 mm wood frame

TREE PROTECTION FENCING

Technical drawing of tree protection fencing showing a 2.4M maximum span, 1.20m height, and 600mm post depth. Specifications include 38 x 89mm top and bottom rails and posts, orange snow-fencing mesh, and a 500mm x 500mm warning sign.
Technical drawing of tree protection fencing showing a 2.4M maximum span, 1.20m height, and 600mm post depth. Specifications include 38 x 89mm top and bottom rails and posts, orange snow-fencing mesh, and a 500mm x 500mm warning sign.

NOTES:

  1. FENCE WILL BE CONTRUCTED USING 38 X 89 mm (2"X4") WOOD FRAME: TOP, BOTTOM AND POSTS. * USE ORANGE SNOW-FENCING MESH AND SECURE TO THE WOOD FRAME WITH "ZIP" TIES OR GALVANZIED STAPLES.

  2. ATTACH A 500mm x 500mm SIGN WITH THE FOLLOWING WORDING: WARNING-HABITAT PROTECTION AREA. THIS SIGN MUST BE AFFIXED ON EVERY FENCE FACE OR AT LEAST EVERY 10 LINEAR METRES.

  • IN ROCKY AREAS, METAL POSTS (T-BAR OR REBAR) DRILLED INTO ROCK WILL BE ACCEPTED.

DETAIL NAME: TREE PROTECTION FENCING DATE: March/08 DRAWN: DM APP'D: RR SCALE: N.T.S. H:\shared\parks\Tree Protection Fencing.pdf
