Attachment 6: Landscape Plan (Lombard North Group)

September 20, 2016Page 1571 section

Site plan detailing tree retention, proposed plantings, and irrigation system requirements.

Landscape plan is for soft landscape only.

280 ISLAND HIGHWAY, VICTORIA, B.C.

Landscape plan for 280 Island Highway, Victoria, B.C., showing building layout, plantings, bike path, and Island Highway frontage.
Landscape plan for 280 Island Highway, Victoria, B.C., showing building layout, plantings, bike path, and Island Highway frontage.

LEGEND

  • DECIDUOUS TREE TO BE A SELECTION OF: FLOWERING DOGWOOD, MOUNTAIN CHERRY. SIZE: 5 CM CAL. MINIMUM. QTY. - 05
  • CONIFER TREE TO BE A SELECTION OF: COLORADO SPRUCE. SIZE: 2.5 M HT. MINIMUM. QTY. - 04
  • SHRUB TO BE A SELECTION OF: STAR MAGNOLIA (DEC), KOREAN SPICE (DEC), PACIFIC DAPHNE (EV). SIZE: #5 CAN. MINIMUM. QTY. - 08
  • SHRUB TO BE A SELECTION OF: SPIREA SP., POTENTILLA SP., RHODODENDRON SP. (EV), HEBE (EV). SIZE: #2 CAN. MINIMUM. QTY. - 38
  • SHRUB TO BE A SELECTION OF: BOXWOOD (EV), JAPANESE HOLLY (EV). SIZE: #2 CAN. MINIMUM. QTY. - 36
  • GROUNDCOVER TO BE A SELECTION OF: PERIWINKLE, KINNIKINNICK. SIZE: #1 CAN. MINIMUM. QTY. - 51
  • GROUNDCOVER TO BE A SELECTION OF: CREEPING JUNIPER. SIZE: 10 CM POT. QTY. AS REQ'D.

NOTES

  • LANDSCAPE AREAS ARE TO BE IRRIGATED WITH A FULLY AUTOMATIC UNDERGROUND IRRIGATION SYSTEM.
  • THIS DRAWING IS CONCEPTUAL ONLY AND NOT INTENDED FOR CONSTRUCTION PURPOSES.
  • THIS DRAWING IS FOR SOFT LANDSCAPE ONLY.

PROJECT INFORMATION

  • Location: 280 ISLAND HIGHWAY, VICTORIA, B.C.
  • Date: MAY 12, 2016
  • Scale: 1 : 200
  • File: SEC 34-IP.DWG
  • Project No: 472-16-01
  • Drawing Title: LANDSCAPE PLAN LP1
