Council Meeting/Documents/Attachment 8: Materials and Color Board
Appendix

Attachment 8: Materials and Color Board

September 20, 2016Page 1651 section

Visual board showing the exterior finishes, including stucco, cedar siding, and stone veneer.

Includes ledgestone veneer and T&G cedar siding.

Attachment 8

Architectural elevation rendering and material board for 280 Island Highway
Architectural elevation rendering and material board for 280 Island Highway

280 ISLAND HIGHWAY - MATERIALS

Close-up of material legend
Close-up of material legend

Material Legend

  1. HORIZONTAL T&G CEDAR SIDING
  2. STUCCO FINISH - LIGHT TAN
  3. STUCCO FINISH - DARK TAN
  4. NATURAL STONE VENEER
  5. DARK GREY METAL FASCIA & FLASHING
  6. BLACK METAL TRIM / RAILING
  7. WHITE METAL WINDOW FRAMES
  8. CONCRETE FINISH
Close-up of elevation measurements and labels
Close-up of elevation measurements and labels

Elevation Measurements

  • T.O. PARAPET: 17.25 m (56'-7")
  • T.O. 4TH FLOOR: 14.25 m (46'-9")
  • T.O. 3RD FLOOR: 11.25 m (36'-11")
  • T.O. 2ND FLOOR: 8.25 m (27'-1")
  • T.O. MAIN FLOOR: 5.25 m (17'-3")
  • AVERAGE GRADE: 0.00 m
  • T.O. BASEMENT FLOOR: -3.25 m (-10'-8")

Vertical Dimensions

  • Parapet to 4th Floor: 3.0 m (9'-10")
  • 4th Floor to 3rd Floor: 3.0 m (9'-10")
  • 3rd Floor to 2nd Floor: 3.0 m (9'-10")
  • 2nd Floor to Main Floor: 3.0 m (9'-10")
  • Main Floor to Average Grade: 5.25 m (17'-3")
  • Average Grade to Basement Floor: 3.25 m (10'-8")
Page 165
