Diagram: Sidewalk closure and crane movement - Helmcken Rd

sidewalk closed sign with alternate route across Helmcken sidewalk or to Watkiss site entrance
Turning movement arc to Watkiss
Annotations for turning movement arc and hoarding dimensions
Hoarding approx 40 feet wide from building to sidewalk
80 feet
Crane parked tight to curb, outriggers on sidewalk and asphalt within delineated area
120 ft long section for crane and truck and trailer between street lights
Annotations for crane parking and truck/trailer section length
BUILDING 8
Pedestrian and cyclist diverted into shopping complex and back to watkiss. Traffic rules would be same as regular entrance into mall from cyclists or pedestrians
Text label describing pedestrian and cyclist diversion route
4 meter lane width maintained
60 ton crane or similiar
Overhead rendering of a 60 ton crane in position
Start shifting Helmcken southbound single lane traffic over to alternate lane at this point.
3.5 LEFT TURN
WHITE THERMOPLASTIC
4.0 N.B. LANE
3.8 N.B. LANE
PLAN 44862
REM 4, REM 5, REM 6, REM 7
Traffic Deliniators
TAC Rb-92
G-11-1 AND G-11-1-TcA
G-12 AND G-15
R-00
R-016
TAC RB-37
