Technical diagrams and maps showing the proposed sign measurements and location at the corner of Island Highway and Wilfert Road.

1 CALL TO ORDER

Sign cabinet: 1.52m x 2.43mExisting sign area: 3.7m²Frontage: 106.6m / 350ft

Sign Proposal

Lower multi-tenant sections of the sign design featuring "PEAK" and "Excalabor Glass" with specified panel heights of 0.23m, 0.13m, 0.13m, and 0.17m, within a total section height of 1.52m

Photo of the existing double-sided pylon sign on-site, indicating a ground clearance of 4.8M / 15.74ft

Aerial site map showing the location at the corner of Island Hwy and Wilfert Rd, with frontage measurements of 63m / 207ft and 106.6m / 350ft

Description

Double sided 1.52m x 2.43m LED illuminated sign cabinet
Flat polycarbonate sign face with flat cut vinyl graphics
Frame & cabinet painted black to match
Internal white LED illumination
Connected to supplied power at sign locations

Total Sign Area: 3.7 Square meters total

Project Details

PROJECT: Client
DATE: 2025
PAGE: 1/1
DESIGNER: PROCIE

Customer Approval

CUSTOMER APPROVAL: ______________________________
DATE: _________________

Terms and Conditions

OUR QUOTE INCLUDES (1) INITIAL DESIGN CONCEPT AND 1 REVISION TO THAT INITIAL DESIGN IF NEEDED.
ADDITIONAL DESIGN CHANGES, OUTSIDE OF WHAT IS ESTIMATED, WILL BE BILLED ACCORDINGLY.
PLEASE NOTE THAT COLOURS SHOWN ON A SCREEN MAY DIFFER FROM FINAL PRODUCT.
THIS SIGN PROPOSAL IS PROTECTED BY COPYRIGHT. ALL RIGHTS RESERVED BY HOUSTON SIGN 90 LTD.
