Project Details

Residence for: Mikaila Mauro & Jaylem Manhas, 2818 Shoreline Drive, View Royal
Date: 06/10/23
Sheet Number: A4.0
Scale: 1:75
Designer: Ronan Design, 3075 Cowie Road, Hornby Island; ronandesign@uniserve.com; 250.335.0165

Architectural drawing showing Section A and Section B of a residential building with specified floor and roof elevations, building dimensions, and property line details.

Elevation Data

Feature	Elevation (m)
Top of South Roof	11.01
Top of North Roof	10.69
Flat Roof	9.59
Eave	9.48
Second Floor	6.84
Main Floor	3.80
Fin. Grade	3.75
Ave. Grade	3.07
Crawlspace	2.10

Site and Structural Annotations

Retaining Wall Max. H: 1.2
Neighbour Property Line
Rockery
Property Line (noted as 3.4 from building in Section B)
Section A Scale 1:75
Section B Scale 1:75

Copyright Notice Copyright material design is exclusive property of Ronan Design. Drawings may not be used without written consent. All dimensions to be verified on site prior to commencing work. Discrepancies to be reported immediately to Ronan Design.
