Attachment 3: Detailed Parking Dimensions

FLOOR PLAN - LEVEL 1

Project Information

• Project Name: CAMDEN TOWNHOUSES
• Project Address: 14 & 14A HELMCKEN ROAD & 6 CAMDEN AVE, VIEW ROYAL
• Project Number: 24026
• Drawing Number: DP03
• Date: 2024-NOV-18
• Drawn By: JS
• Reviewed By: RP
• Scale: As Noted

Revision History

---

1 FIRST FLOOR PLAN (Scale 1:100)

The first floor plan details the layout for several residential units and associated site infrastructure.

Unit Summary

• Unit A - L1: 607 SF (1 unit), 610 SF (5 units)
• Unit B - L1: 601 SF (1 unit), 604 SF (3 units)
• Unit C - L1: 571 SF (1 unit)
• Unit D - L1: 600 SF (1 unit)

Site Features and Infrastructure

• Parking: Standard Parking Stalls and Small Car Parking Stalls are located throughout the site.
• Access: Permeable Pavers Strata Access Road and multiple Driveways.
• Utilities: Heat Pumps for each unit, Hydro Vault, and Electrical (ELEC) areas.
• Amenities: Bike Rack (6 Class II Stalls), Canada Post Mailboxes, and Site Sign.
• Landscaping: 6' High Wood Fence, Retaining Wall, and Aluminum Picket Railing.
• Setbacks: 3 Phase Powerline Setback and Heat Pump Setback.
• Elevation: Level 1 is set at 78'-3" (23.85 m).

---

2 SITE ADDRESS SIGN (Scale 1:25)

Detail for the address signage for 6 Camden.

• Components:
  • Concrete Plinth
  • Cutout Aluminum Sign
  • LED Backlit
• Dimensions:
  • Total Height: 842 mm
  • Total Width: 2159 mm
  • Aluminum Sign Width: 1741 mm
• Placement: Aligned with Level 1 elevation of 78.25' (23.85 m).
