Attachment 3 - Sign Plans – KnightSigns

July 9, 2024Page 2521 section

Technical design specifications and concept renderings for the proposed digital display sign at Six Mile Pub.

Firm: KnightSignsDesign Date: 08-05-24Sign Type: Illuminated digital message centre

Attachment 3

SPECIFICATIONS

Remove existing 4'2" x 3' read-o-graph sign and wooden frame, replace with new 960mm x 1280mm digital message centre with new enclosing 10ga aluminum cabinet 6" deep. Mounted flush to the building exterior. Cabinet sides to be painted to match to Pub brown cladding panels Colour TBD.

Shop drawing required
Survey required

COLOURS + FINISHES

ID	Description	Details
P1	Colour Match	Dark Brown TBD

GRAPHICS & MEASUREMENTS

Rendering of the digital message centre graphic showing the text "Artisan Food. Craft Beer. Historic Setting. Six Mile Pub & Eatery. Handcrafted cuisine in British Columbia's oldest pub. Established 1855."

Width: 4'-2 11/32" / 1,280 mm
Height: 3'-1 25/32" / 960 mm

SIDE VIEW

Side profile diagram of the sign cabinet

Depth: 6" / 152 mm

CONCEPT - NTS REFERENCE ONLY

CURRENT CONDITIONS

Project Information

Project: Six Mile Pub + Eatery - Digital Display
Client: Six Mile Pub + Eatery
Quote Number: 22350-05-24-SMPRG
Date: 08-05-24
Account Manager: Lynda Van de Putte
Drawn/Revised By: Rachelle
Scale: 1 : 10
Sign 1: MOUNTED MESSAGE CENTRE
Illumination: ILLUMINATED (digital)
Quantity: 1
Address: 494 Island Hwy, Victoria, BC, V9B 1H5
