Committee of the Whole/Documents/Attachment 2: Survey & Architectural Plans and Renderings (Conceptual 3D Images and 2D Elevations)
Appendix

Attachment 2: Survey & Architectural Plans and Renderings (Conceptual 3D Images and 2D Elevations)

January 9, 2024Pages 151–1522 sections

Visual appendices providing 3D conceptual renderings and 2D elevation drawings of the proposed multi-unit residential building.

Includes North West Elevation for Helmcken RoadIncludes North East Elevation for Camden AvenueShows contemporary design with natural wood features and stone-clad entrance

Conceptual 3D Images

Conceptual 3D rendering showing the multi-story residential building from a street corner perspective
Conceptual 3D rendering showing the multi-story residential building from a street corner perspective
Conceptual 3D rendering showing the building's facade featuring glass balconies and a prominent stone-clad vertical element
Conceptual 3D rendering showing the building's facade featuring glass balconies and a prominent stone-clad vertical element

Note: Updated landscape details are not shown on 3D images, see Landscape Plan for information.

Close-up conceptual 3D rendering of the building entrance featuring a timber-supported canopy and architectural stone pillars
Close-up conceptual 3D rendering of the building entrance featuring a timber-supported canopy and architectural stone pillars
Page 151–152

2D Elevations

Page 151–152
