2nd Floor Plan, 3rd floor Plan - Proposed Residential Development
January 9, 2024Page 1571 section
Architectural floor plans for the second and third floors of the proposed residential development at Camden and Helmcken.
14, 14A Helmcken Road and 6 Camden AvenueTotal 2nd floor area: 686.1 m2Total 3rd floor area: 533.9 m2Joe Newell Architect Inc.
PROPOSED RESIDENTIAL DEVELOPMENT - CAMDEN AVENUE AND HELMCKEN ROAD
1. 2nd Floor Plan (Scale 1:100)
2nd Floor - Areas - Included:
| Floor | Unit | Unit Type | Area (sq m) | Area (sq ft) |
|---|---|---|---|---|
| 2nd Floor Plan | 201 | 2 bedroom | 69.7 m2 | 751 s.f. |
| 202 | 1 bedroom | 51.6 m2 | 555 s.f. | |
| 203 | 1 bedroom | 51.6 m2 | 555 s.f. | |
| 204 | 1 bedroom | 51.6 m2 | 555 s.f. | |
| 205 | 2 bedroom | 71.1 m2 | 766 s.f. | |
| 206 | 2 bedroom | 71.4 m2 | 768 s.f. | |
| 207 | 2 bedroom | 71.4 m2 | 768 s.f. | |
| 208 | 3 bedroom | 94.5 m2 | 1,017 s.f. | |
| 209 | 2 bedroom | 76.6 m2 | 825 s.f. | |
| Total: | 686.1 m2 | 7,385 s.f. |
Area Legend
- Balcony
- Roof
- Residential Circulation
- Residential Unit - 1 bedroom
- Residential Unit - 2 bedroom
- Residential Unit - 3 bedroom
- Bike room & Service
2. 3rd Floor Plan (Scale 1:100)
3rd Floor - Areas - Included:
| Floor | Unit | Unit Type | Area (sq m) | Area (sq ft) |
|---|---|---|---|---|
| 3rd Floor Plan | 301 | 1 bedroom | 49.8 m2 | 536 s.f. |
| 302 | 1 bedroom | 51.7 m2 | 556 s.f. | |
| 303 | 1 bedroom | 51.7 m2 | 556 s.f. | |
| 304 | 2 bedroom | 70.2 m2 | 756 s.f. | |
| 305 | 2 bedroom | 71.4 m2 | 768 s.f. | |
| 306 | 2 bedroom | 71.4 m2 | 768 s.f. | |
| 307 | 1 bedroom | 55.9 m2 | 602 s.f. | |
| 308 | 1 bedroom | 55.9 m2 | 602 s.f. | |
| 309 | 1 bedroom | 55.9 m2 | 602 s.f. | |
| Total: | 533.9 m2 | 5,747 s.f. |
Area Legend
- Balcony
- Roof Deck
- Residential Circulation
- Residential Unit - 1 bedroom
- Residential Unit - 2 bedroom
- Bike room & Service
