Roof Plan, Pergola @ Roof, Project Sign, Fence Elevation - Proposed Residential Development
January 9, 2024Page 1581 section
Detailed drawings for the roof plan, project signage, and fencing for the proposed residential development.
Drawing A.5September 11, 2023Proposed roof garden area: 75m2
PROPOSED RESIDENTIAL DEVELOPMENT: CAMDEN AVENUE AND HELMCKEN ROAD
1. Roof Plan
Scale: 1:100
[Diagram: Roof Plan showing building top-level layout, including garden areas, sheet metal roofing, stairwells, and mechanical locations.]
Area Legend
| Symbol | Description |
|---|---|
| Dotted hatch | Roof garden / Regular Paving Slab 18x18 |
| Diagonal line hatch | Butterfly Sheet Metal Roofing |
| Solid white | Flat roof |
| Circle with dot | Rain drain pipe |
| MU | Mechanical unit / air supply |
| Dashed line | Line of Corridor below |
Key Plan Notes:
- Proposed roof garden area: 75 m²
- Rooftop area: 75 m²
- Typical flat roof construction: 2 ply SBS roofing membrane with minimum 2% slope to drains as indicated.
- The plan identifies "Stair #1", "Stair #2", "Elevator Shaft", "custodial" area, and "9 bikes" storage.
- Major Dimensions: Total building width 34.4 m; total building depth 34.13 m.
2. Pergola @ Roof
Scale: 1:50
[Diagram: Elevation and Plan views of the roof-mounted pergola structure.]
Elevation - E Specifications:
- Rafters: 38x140mm (2”x6”) cedar rafters
- Beams: 38x184mm (2”x8”) cedar beams
- Posts: 178x178mm (8”x 8”) cedar posts
- Lighting: Ceiling mounted exterior LED light.
- Heights: 2.51 m total structure height; 2.0 m clear height to the bottom of the beams.
Plan Specifications:
- Overall Dimensions: 5.52 m width (consisting of 2.77 m and 2.75 m spans) by 2.8 m depth.
- Includes detailed roofing for the "Elevator" and "Stair #1" sections, each noting: "Typical flat roof: 2 ply SBS roofing membrane w/ min. 2% slope to drains as indicated."
3. Project Sign
Scale: 1:50
[Diagram: Elevation of the proposed project signage.]
- Lighting: Low profile exterior spot light fixture installed in front to illuminate project sign.
- Materials and Lettering:
- Cut-out lettering c/w black backing.
- Applied Lettering.
- Concrete R. Wall foundation.
- Dimensions: 1.52 m width by 1.22 m height.
- Signage Content: "PROJECT NAME", "14 HELMCKEN ROAD".
4. Fence Elevations
Scale: 1:50
Metal Picket Fence
[Diagram: Elevation view of a metal picket fence.]
- Dimensions: 1.83 m width per panel; 1.22 m height above finished grade (F.G.).
Wood Fence
[Diagram: Elevation view of a wood fence.]
- Components:
- 1x6 vertical cedar boards.
- 2x4 cedar top cap.
- 6x6 cedar posts.
- Dimensions: Maximum height of 2 m; 2.5 m post spacing.
Page 158
