339 Island Highway - Site Sections A303

June 13, 2023Page 831 section

Sectional drawings illustrating the building's height and setback in relation to site topography and neighboring properties.

2. APPROVAL OF AGENDA (motion to approve)
Scale: 1:200Max Roof height: approx 48.80m

Boardwalk REIT - View Royal BC

339 Island Highway - Site Sections

Sheet: A303
Scale: 1:200
Architect: dHKarchitects

1 Site Section

Scale: 1:230

Building section diagram showing floor levels and sloped site profile
Building section diagram showing floor levels and sloped site profile
Rendering of foggy coniferous trees used as a background for the site section
Rendering of foggy coniferous trees used as a background for the site section
Rendering of foggy coniferous trees used as a background for the site section
Rendering of foggy coniferous trees used as a background for the site section
Elevation / Level Description
48.80 Roof
46.60 Roof
43.40 L7
40.20 Roof
27.40 L2
24.20 Main Level
21.00 P1
17.80 P2
+/- 51.40 Roof (Neighbouring Property)

Site Constraints and Locations:

  • PROPERTY LINE
  • 6M SETBACK
  • 8M SETBACK
  • 339 ISLAND HIGHWAY
  • R.O.W.
  • NEIGHBOURING PROPERTY

2 Neighbour Property View - Google Earth Image

Google Earth rendering of the project site and surrounding neighbourhood trees
Google Earth rendering of the project site and surrounding neighbourhood trees

3 Neighbour Property View - Google Earth Image

Google Earth rendering from an alternate perspective showing the terrain and greenery
Google Earth rendering from an alternate perspective showing the terrain and greenery
