Appendix
339 Island Highway L2 - 27.4m A204
June 13, 2023Page 1074 sections
Architectural floor plan for Level 2 of the proposed development at 339 Island Highway, showing unit layouts and square footage.
339 Island HighwayLevel L2 at 27.4m elevationScale 1:200Architect: dHKarchitects
339 Island Highway
Boardwalk REIT
View Royal BC
Sheet: A204
Title: L2 - 27.4m
Scale: 1:200
Architect: dHKarchitects
Page 107
Site Plan Overview
The site plan for 339 Island Highway shows a residential development bounded by Island Highway to the north and Prince Robert Dr to the west. The layout features multiple building wings arranged around a central circular courtyard and landscaped common areas.
Access roads wind through the site, including a designated "COMMERCIAL LOADING ZONE" on the western side. Surface parking stalls are numbered from 307 to 338.
Page 107
Unit Types and Specifications
The following unit configurations and typical dimensions are indicated for Level 2 (Elevation 27.4m):
Unit Summary Table
| Unit Type | Area (SF) | Typical Features and Dimensions |
|---|---|---|
| 3-BED | 1105 SF | |
| 2-BED | 910 SF | |
| 2-BED | 845 SF | |
| 2-BED | 840 SF | Main BR: 10' x 12', 2nd BR: 9' x 12', LR + DR: 11' x 18', 9' W Kit, Deck: 8' x 10', Bathrooms: 5' x 8' & 5' x 8.5', Laundry: 5' x 8' |
| 1-BED | 715 SF | |
| 1-BED | 675 SF | |
| 1-BED | 665 SF | |
| 1-BED | 630 SF | Main BR: 10' x 12', LR + DR: 11.4' x 20' or 11' x 18', Kit: 8.5' or 9' wide, Deck: 8' x 10', Bath: 5' x 9' |
| 1-BED | 600 SF | Deck: 8' x 9'6" |
| Studio | 578 SF |
Page 107
Site Details
- Building Elevation: 27.4m (Level 2)
- Setbacks:
- 6m / 6.0m (various locations along property lines)
- 8m (southern property line)
- Parking Stalls: 307, 308, 309, 310, 311, 312, 313, 314, 315, 316, 317, 318, 319, 320, 321, 322, 323, 324, 325, 326, 327, 328, 329, 330, 331, 332, 333, 334, 335, 336, 337, 338.
Page 107
