339 Island Highway Roof Plan - 46.6m A210
June 13, 2023Page 1131 section
Architectural roof plan for the proposed development at 339 Island Highway.
339 Island HighwayRoof Plan at 46.6m elevationScale 1:200Architect: dHKarchitects
339 Island Highway
Project Information
- Project Name: 339 Island Highway
- Location: View Royal, BC
- Client: Boardwalk REIT
- Architect: dHKarchitects
Drawing Details: Roof Plan - 46.6m
- Drawing Number: A210
- Scale: 1:200
The roof plan illustrates the building footprints, landscaping, and site circulation for the development.
Site Features:
- Access Roads: The site is bounded by Island Highway to the north and Prince Robert Dr to the west.
- Parking Stalls: Numbered parking stalls are provided on-site, specifically stalls 307, 308, 309, 310, 311, 312, 313, 314, 315, 316, 317, 318, 319, 320, 321, 322, 323, 324, 325, 326, 327, 328, 329, 330, 331, 332, 333, 334, 335, 336, 337, and 338.
- Loading Zone: A "COMMERCIAL LOADING ZONE" is located adjacent to the parking area.
- Setbacks: The plan notes setbacks of 6m, 6.0m, and 8m at various points around the property perimeter.
