STORMONT ROAD TRAFFIC CALMING UPDATE

Feburary 15, 2023 Committee of the Whole Budget Meeting: Stormont Road Traffic Calming (N-081) – additional details to be provide on other potential options

Photo of Stormont Road with an existing speed hump and road markings
Photo of Stormont Road with an existing speed hump and road markings
Aerial map of the Stormont Road residential area
Aerial map of the Stormont Road residential area
Page 301–309

BACKGROUND

  • Traffic Counter: <50km/hr all instances
  • Currently two (2) existing speed humps on Stormont Road
  • Project included at request of Council
  • Budget: $8,000
Project Summary document for Capital Project N-081, Stormont Road traffic calming
Project Summary document for Capital Project N-081, Stormont Road traffic calming

Council directed staff to seek other options due to Staff concerns regarding:

  • Precedence setting
  • Effectiveness of a third speed hump in significant short proximity of others
  • Emergency service concerns

BACKGROUND (continued)

A third speed hump would cause distance between each other to be half to a third of the distance stipulated in the Traffic Calming Policy #5200-016

  • Precedence (speeds and location of measures)
  • Additional and cumulative delays for fire trucks and emergency services
Annotated aerial map showing distances of 55m, 60m, and 90m between existing and potential speed hump locations
Annotated aerial map showing distances of 55m, 60m, and 90m between existing and potential speed hump locations
Page 301–309

OTHER MEASURES

  • Chicane / Choker / Curb Extension
    • Illustration of a chicane traffic calming measure
      Illustration of a chicane traffic calming measure
    • Illustration of a choker or curb extension traffic calming measure
      Illustration of a choker or curb extension traffic calming measure
  • Raised Medians (Intersection or Mid-Block)
  • One Way Street
  • No-Thru Street

Excerpt: BC Active Transportation Design Guide

Page 301–309

CHICANE - EXAMPLE

Aerial site plan showing a proposed chicane layout using precast concrete planters on Stormont Road
Aerial site plan showing a proposed chicane layout using precast concrete planters on Stormont Road
Detailed aerial view of the proposed chicane planter placement
Detailed aerial view of the proposed chicane planter placement
Page 301–309

CHICANE - PROPOSAL

Quick-Build Principles: Town of View Royal Active Transportation Network Plan:

  • Flexible
  • Inexpensive
  • Allows for adjustments post implementation
  • Does not require removal of existing infrastructure
  • Geometric layout of the road does not require changes
  • No significant impacts to utilities or drainage

City of Vancouver “Slow Streets Program” – Street Barrier Design for Narrow Streets

Rendering of street barrier designs from the City of Vancouver "Slow Streets Program"
Rendering of street barrier designs from the City of Vancouver "Slow Streets Program"

Stormont Road – Installation on Sidewalk Side of the Road

Photo of Stormont Road indicating the sidewalk side of the road for the proposed installation
Photo of Stormont Road indicating the sidewalk side of the road for the proposed installation
Page 301–309

RECOMMENDATION

THAT the Committee recommend to Council that Staff proceed with installing a quick build chicane on Stormont Road as part of Capital Project N-081

Ivan Leung, P.Eng Director of Engineering & Parks Engineering@viewroyal.ca
