B.C. Land Surveyor's Site Plan - 275 Kerwood St

B.C. LAND SURVEYOR'S SITE PLAN OF: LOT 1-A, BLOCK 12, SECTION 27, ESQUIMALT DISTRICT, PLAN 1688

SCALE: 1:250

Parcel Identification Number (PID) 001-622-161

SITE AREA 866± m²

MUNICIPALITY TOWN OF VIEW ROYAL

CIVIC ADDRESS 275 KERWOOD STREET VIEW ROYAL, BC

ZONING R-1

Elevators are geodetic based on GPS measurements.
Note: Only trees with Trunk greater than 0.20m are identified. Consult Arborist to verify tree species.
Grade shots are taken at the point marked X.
Contours are descriptive, and only accurate to +/- 0.5m interval.
● - denotes Iron Pin Found
TRD - denotes Deciduous Tree Type
TRC - denotes Coniferous Tree Type
☼ - denotes Power pole
⊚ - denotes unmarked manhole
T.XX - Top of Wall

Plan Notes and Details:

All rights reserved. No person may copy, reproduce, transmit or alter this document in whole or in part without the written consent of the signatory.
This document was prepared for the exclusive use of our client, Dennis Lau.
This document is intended for use as a topographic plan. It is based on Land Title Office records, and does not represent a boundary survey. Critical lot dimensions and areas must be confirmed by a proper cadastral survey.
Undersurface charges and covenant will not be shown on this survey unless such documents are provided and it can be shown in two dimensional view.
Explorer Land Surveying Inc., accepts no responsibility or liability for any damages that may be suffered by a third party as a result of any decisions made or actions taken based on this document.

Measurements, Setbacks, and Elevations:

Chimney proj. into setback: 11" [279 mm]
Adjoint Dwelling Deck setback: 7'-5" [2256 mm]
15m setback to the natural boundary
Building/Lot dimensions: 6'-0" [1829 mm], 33'-9" [10287 mm], 6'-9 1/2" [2074 mm], 49'-8 1/2" [15150 mm]
Main Finished Floor: 12.077 m datum
Average Grade (May 15, 2019): 10.36 m Datum
Deck Elevation: 2.5m

Map Locations and Features:

Surveyor's Certification:

MAY 15, 2019.
