WR1 - LEVEL 2 - 1720 Wilfert Rd
July 13, 2021Page 211 section
Floor plan for Level 2 of the proposed development at 1720 Wilfert Road.
1-bed and 2-bed units
1720 Wilfert Rd - WR1 - LEVEL 2
Project Details
- Project Name: 1720 Wilfert Rd
- Drawing Title: WR1 - LEVEL 2
- Drawing Number: AA-105
- Project No.: 027 - RFP
- Date: MAR. 30, 2021
- Scale: 1:150
- Status: REZONING V1
- Designed by: MKM
- Drawn by: VC
- Checked by: MKM
Contact Information
Developer / Designer DESIGN BUILD SERVICES Suite 360-800 Kelly Rd Victoria, BC, V9B 6J9 Phone: (250) 474-7020 Email: matt@dbsvictoria.com
Architect JACK JAMES ARCHITECT - AIBC 2288 Selwyn Rd, Victoria, BC, V9B 3K8 Phone: (250) 478-9388 Email: jjamesarchitect@gmail.com
Revision Schedule
| REV# | DATE | DESCRIPTION |
|---|---|---|
| 1 | ?? | REZONING |
Unit Breakdown (Level 2)
The architectural floor plan for Level 2 includes the following residential units:
| Unit Size (sq. ft) | Unit Type |
|---|---|
| 986 sq.ft | 2 Beds |
| 1057 sq.ft | 2 Beds |
| 850 sq.ft | 2 Beds |
| 925 sq.ft | 2 Beds |
| 833 sq.ft | 1 Bed + Den |
| 656 sq.ft | 1 Beds |
| 925 sq.ft | 2 Beds |
| 850 sq.ft | 2 Beds |
| 1055 sq.ft | 2 Beds |
| 990 sq.ft | 2 Beds |
| 686 sq.ft | 1 Beds + Den |
| 686 sq.ft | 1 Beds + Den |
| 686 sq.ft | 1 Beds + Den |
| 733 sq.ft | 1 Beds + Den |
| 890 sq.ft | 2 Beds |
| 627 sq.ft | 1 Beds + Den |
| 670 sq.ft | 1 Beds + Den |
| 670 sq.ft | 1 Beds + Den |
| 670 sq.ft | 1 Beds + Den |
