WR2 - LEVEL 2 - Building B - 1720 Wilfert Rd
July 13, 2021Page 231 section
Floor plan for Level 2 of Building B at 1720 Wilfert Road.
Multiple residential layouts
1720 Wilfert Rd
Project Information
| Field | Details |
|---|---|
| Project No. | 027 - RFP |
| Date | MAR. 30, 2021 |
| Designed by | MKM |
| Drawn by | VO |
| Checked by | MKM |
| Sheet Name | WR2 - LEVEL 2 |
| Sheet No. | AB-109 |
| Scale | 1 : 150 |
| Rezoning Status | REZONING V1 |
Revision Schedule
| REV# | DATE | DESCRIPTION |
|---|---|---|
| 1 | 2021/03/30 | REZONING |
Contact Information
Developer / Designer Design Build Services (250) 474-7020 matt@dbsvictoria.com Suite 360-800 Kelly Rd Victoria, BC, V9B 6J9
Architect Jack James Architect - AIBC (250) 478-9388 jjamesarchitect@gmail.com 2288 Selwyn Rd, Victoria, BC, V9B 3K8
Floor Plan: Level 2-Building B
The floor plan illustrates the layout for Level 2 of Building B at 1720 Wilfert Rd. The plan includes a grid system with axes 1-29 and A-K. A central corridor provides access to residential units on both sides.
Unit Summary:
- 950 sq.ft (2 Beds + Den): 2 units
- 1060 sq.ft (2 Beds + Den): 2 units
- 690 sq.ft (1 Beds): 2 units
- 680 sq.ft (1 Beds): 2 units
- 685 sq.ft (1 Beds + Den): 2 units
- 965 sq.ft (2 Beds): 1 unit
- 875 sq.ft (2 Beds): 1 unit
- 832 sq.ft (2 Beds): 1 unit
- 962 sq.ft (2 Beds): 1 unit
- 1090 sq.ft (2 Beds + Den): 1 unit
- 1140 sq.ft (2 Beds + Den): 1 unit
- 1125 sq.ft (2 Beds + Den): 1 unit
- 850 sq.ft (1 Beds + Den): 1 unit
- 610 sq.ft (1 Beds + Den): 1 unit
The drawing also includes a north arrow and indicates "UP" for a stairwell near unit 1060 sq.ft.
