Site Plan of Lot C, Sections 6 and 103, Esquimalt District

June 14, 2016Page 1191 section

Legal site survey showing existing topographic conditions and site boundaries.

2 APPROVAL OF AGENDA
October 22, 2011Island Land Surveying Ltd.

SITE PLAN OF LOT C, SECTIONS 6 AND 103, ESQUIMALT DISTRICT, PLAN VIP80154.

SCALE = 1:250 All distances are in metres.

Note: Elevations shown are based upon geodetic datum.

Legend

  • 647 0.30 Oak: Denotes tree location, tag number, diameter and species
  • 30.2: Denotes elevation
  • 30.2 (with bar under): Denotes bottom of bank elevation
  • 30.2 (with bar over): Denotes top of bank elevation

The parcel is subject to charges:

  • Right of Way 47769G
  • Statutory Right of Way ED63991, EE65527 EX162888, FA16792, FA16793 & FA21704
  • Easement EX162892
Detailed site plan of Lot C showing topographic contours, a large central area labeled "Bottom of excavated rock", and an extensive tree inventory with tag numbers, diameters, and species (e.g., Oak, Arbutus, Fir). The plan indicates property boundaries adjacent to Nursery Hill Drive, Lot 1 and Lot 23 Strata Plan VIS6081, Lot D Plan VIP80154, Lot 1 Plan VIP60330, and Strata Plan VIS6613.
Detailed site plan of Lot C showing topographic contours, a large central area labeled "Bottom of excavated rock", and an extensive tree inventory with tag numbers, diameters, and species (e.g., Oak, Arbutus, Fir). The plan indicates property boundaries adjacent to Nursery Hill Drive, Lot 1 and Lot 23 Strata Plan VIS6081, Lot D Plan VIP80154, Lot 1 Plan VIP60330, and Strata Plan VIS6613.

Manholes

  • SMH #567 - Lid Elev=33.67
    • Invert Elev=31.86 0.20 PVC
    • Invert Elev=31.80 0.20 PVC
    • Invert Elev=31.87 0.20 PVC
  • DMH #564 - Lid Elev=33.58
    • Invert Elev=31.80 0.20 PVC
    • Invert Elev=31.77 0.30 PVC
    • Invert Elev=31.78 0.30 PVC

Detail Plan

Scale = 1:2000

Project Information

  • File: 97-SEVENVD-MN2
  • Date: October 22, 2011
  • Island Land Surveying Ltd.
  • 1-15 Cadillac Avenue
  • Victoria, B.C. V8Z 1T3
  • TEL 250.475.1515 FAX 250.475.1516
  • www.islandsurveying.ca
