Committee of the Whole/Documents/Proposed Foundation Position Lot Drawings
Appendix

Proposed Foundation Position Lot Drawings

June 14, 2016Pages 137–1382 sections

Survey plans for specific lots showing foundation footprints relative to setbacks.

2 APPROVAL OF AGENDA
Lot 3 and Lot 15, Section 98

PROPOSED FOUNDATION POSITION UPON LOT 3, SECTION 98, ESQUIMALT DISTRICT. PLAN EPP55963.

Survey plan for Lot 3, Section 98, Esquimalt District, showing the proposed foundation position, building setbacks, and lot dimensions. The lot area is noted as 358.8 m².
Survey plan for Lot 3, Section 98, Esquimalt District, showing the proposed foundation position, building setbacks, and lot dimensions. The lot area is noted as 358.8 m².

SCALE=1:400. All distances are in metres.

The parcel is subject to charges:

  • Covenant FB408215 & CA4921870
  • Statutory Right of Way CA4041989, CA4921897, CA4921900
  • Statutory Right of Way CA4921901 & CA4921903
File Information Zoning and Set-backs
File: 97-LIMONA-P6-PP
Date: May 5, 2016		 Zoning: CD-19
Minimum Set-backs
Island Land Surveying Ltd.
1-15 Cadillac Avenue
Victoria, B.C. V8Z 1T3
TEL 250.475.1515 fax 250.475.1516
www.islandsurveying.ca		 Front: 4.5m
Rear: 6.0m
Side: 1.2m
Side, Flanking: 4.0m
Page 137–138

PROPOSED FOUNDATION POSITION UPON LOT 15, SECTION 98, ESQUIMALT DISTRICT. PLAN EPP55963.

Survey plan for Lot 15, Section 98, Esquimalt District, illustrating the proposed foundation position including a deck, lot dimensions, and adjacency to a park. The lot area is noted as 370.7 m².
Survey plan for Lot 15, Section 98, Esquimalt District, illustrating the proposed foundation position including a deck, lot dimensions, and adjacency to a park. The lot area is noted as 370.7 m².

SCALE=1:400. All distances are in metres.

The parcel is subject to charges:

  • Covenant FB408215 & CA4921870
  • Statutory Right of Way CA4041989, CA4921897, CA4921900
  • Statutory Right of Way CA4921901 & CA4921903
File Information Zoning and Set-backs
File: 97-LIMONA-P6-PP
Date: May 5, 2016		 Zoning: CD-19
Minimum Set-backs
Island Land Surveying Ltd.
1-15 Cadillac Avenue
Victoria, B.C. V8Z 1T3
TEL 250.475.1515 fax 250.475.1516
www.islandsurveying.ca		 Front: 4.5m
Rear: 6.0m
Side: 1.2m
Side, Flanking: 4.0m
Page 137–138
