Site Plans and Proposed Foundation Positions - Phase 7

June 14, 2016Pages 155–1574 sections

Lot-specific layouts for Phase 7 of the Thetis Vale development.

2 APPROVAL OF AGENDA
Lots 10 and 20 detailed

LIMONA CONSTRUCTION THETIS VALE PHASE 7

Page 155–157

TREE REMOVAL DETAIL - PLAN

Site plan showing lot layout, green spaces, and tree removal areas for Thetis Vale Phase 7
Site plan showing lot layout, green spaces, and tree removal areas for Thetis Vale Phase 7

Project Data

Field Value
PROJECT No. 20142701
DATE 2014-05-23
DRAWN BY DAH
DESIGNED BY DAH
SCALE 1:1000
REV A
DWG No. 2701-00-P.G.1.112

Legend

  • CREST OF GULLEY (dashed line)
  • SPEA BOUNDARY (dash-dot line)

Map Annotations

  • Green Spaces:
    • GREEN SPACE 1.60 ha. (central area)
    • GREEN SPACE 0.31 ha. (adjacent to Lot 12)
    • GREEN SPACE 0.01 ha. (adjacent to Lot 24)
    • GREEN SPACE 0.01 ha. (adjacent to Lot 9)
    • GREEN SPACE (at bottom right corner)
  • Environmental and Removal Notes:
    • 10m SPEA (indicated along the eastern boundary)
    • SELECT TREES TO BE REMOVED IN THIS AREA (indicated along the boundary between Green Space and Lots 27-33)
  • Property Exclusions:
    • NOT PART OF SUBJECT PROPERTY: 0.80 ha (WOODWORTH), 1 Standard Lot : 38 (TY), 7947 sq.ft.
Page 155–157

PROPOSED FOUNDATION POSITION UPON PROPOSED LOT 20, SECTION 98, ESQUIMALT DISTRICT, PROPOSED PLAN EPP

Detailed site plan for Lot 20 showing proposed foundation and surrounding features
Detailed site plan for Lot 20 showing proposed foundation and surrounding features
Scale bar for Lot 20 plan
Scale bar for Lot 20 plan

NOTE: Building position must be confirmed by approving authorities prior to construction. Existing or proposed Rights of Way, Easements or Covenants are not shown.

Lot Information: Lot 20

  • Area: 400.2 m²
  • Surroundings: Bordered by Lot 19, Lot 21, and a Road with a proposed gutter and sidewalk.
Project reference and zoning setback table
Project reference and zoning setback table

Project Details

Field Value
File 97-LIMONA-P6-P7-MF3
Date May 9, 2016
Zoning CD-19

Minimum Set-backs

Set-back Distance
Front 4.5m
Rear 6.0m
Side 1.2m
Side, Flanking 4.0m

Island Land Surveying Ltd. 1-15 Cadillac Avenue Victoria, B.C. V8Z 1T3 TEL 250.475.1515 fax 250.475.1516 www.islandsurveying.ca

Page 155–157

PROPOSED FOUNDATION POSITION UPON PROPOSED LOT 10, SECTION 98, ESQUIMALT DISTRICT, PROPOSED PLAN EPP

Detailed site plan for Lot 10 showing proposed foundation and surrounding features
Detailed site plan for Lot 10 showing proposed foundation and surrounding features
Scale bar for Lot 10 plan
Scale bar for Lot 10 plan

NOTE: Building position must be confirmed by approving authorities prior to construction. Existing or proposed Rights of Way, Easements or Covenants are not shown.

Lot Information: Lot 10

  • Area: 520.6 m²
  • Surroundings: Bordered by Lot 11, a Road with a proposed gutter and driveway, and adjacent Park areas.

Project Details

Field Value
File 97-LIMONA-P6-P7-MF3
Date May 9, 2016
Zoning CD-19

Minimum Set-backs

Set-back Distance
Front 4.5m
Rear 6.0m
Side 1.2m
Side, Flanking 4.0m

Island Land Surveying Ltd. 1-15 Cadillac Avenue Victoria, B.C. V8Z 1T3 TEL 250.475.1515 fax 250.475.1516 www.islandsurveying.ca

Page 155–157
