Preliminary Site Plan - 1950 Watkiss Way

June 14, 2016Page 1721 section

Site-wide architectural layout showing the building footprint and underground parkade access.

2 APPROVAL OF AGENDA
Plan A0.1D-Architecture

PRELIMINARY SITE PLAN - 1950 WATKISS WAY, VIEW ROYAL BC

Project Information:

  • Architect: D-ARCHITECTURE (Daryoush Firouzi Architecture Inc.)
  • Client: Darvishi Investments Inc.
  • Project No: 1403
  • Date: April 25th 2014
  • Scale: N/A
  • Sheet Number: A0.1
Preliminary site plan for 1950 Watkiss Way, showing a detailed building footprint with interior unit layouts, numbered parking stalls, topographic contour lines, and surrounding area labels.
Preliminary site plan for 1950 Watkiss Way, showing a detailed building footprint with interior unit layouts, numbered parking stalls, topographic contour lines, and surrounding area labels.

The document contains the following handwritten annotations and labels:

  • BURNSIDE WATKISS PARK SECTION
  • SUBJECT PROPERTY (with an arrow pointing to the building at 1950 Watkiss Way)
  • 1950 (located near the subject property building)
  • 1900 (located near the adjacent property area)
  • WATKISS WAY (identifying the road on the right side of the plan)
  • ATTACHMENT 4

The site plan illustrates a multi-unit building layout with dimensions and numbered parking spaces (e.g., stalls 13, 24, 33, 36, and 38 are visible). The plan also shows the orientation of the site relative to Watkiss Way and the adjacent Burnside Watkiss Park area.
