Preliminary Elevations - 1950 Watkiss Way

June 14, 2016Page 1771 section

Exterior facade drawings from South, North, East, and West viewpoints.

2 APPROVAL OF AGENDA
Materials include Hardie plank siding and natural wood siding

PRELIMINARY ELEVATIONS - 1950 WATKISS WAY, VIEW ROYAL, BC

Architectural drawing showing the South, North, East, and West elevations of a multi-story building located at 1950 Watkiss Way, including an exterior materials legend and height markers.
Architectural drawing showing the South, North, East, and West elevations of a multi-story building located at 1950 Watkiss Way, including an exterior materials legend and height markers.

EXTERIOR MATERIALS

CODE MATERIAL
1 8" HARDIE PLANK SIDING
2 NATURAL/IMITATION WOOD SIDING
3 HARDIE PANELS CEMENTITIOUS PANEL SIDING
4 HARDIE PANELS CEMENTITIOUS PANEL SIDING (WING WALLS)
5 NATURAL/CULTURED VENEER STONE
6 ALUMINUM STOREFRONT WINDOWS/DOORS AT MAIN FLOOR
7 VINYL WINDOWS
8 ALUMINUM RAILING

SOUTH ELEVATION

  • 18m
  • 17m at property line
  • SIDEWALK
  • BUS STOP

NORTH ELEVATION

EAST ELEVATION

WEST ELEVATION

  • 24m
  • 23m
  • 22m
  • 21m
  • 20m
  • 19m
  • 18m
  • 17m

Project Details:

  • Project: 1950 WATKISS WAY, VIEW ROYAL, BC
  • Drawing Name: PRELIMINARY ELEVATIONS
  • Date: JAN 18 2016
  • Project No: 339
  • Sheet No: A2.1
  • Attachment: ATTACHMENT 9
Page 177
