Preliminary Sections - 1950 Watkiss Way

June 14, 2016Page 1781 section

Cross-sectional drawings showing internal building heights and site grading.

2 APPROVAL OF AGENDA

Interior Elevations included

1950 Watkiss Way, View Royal BC

Preliminary Sections

Architect: D-Architecture (Daryoush Firouzi Architecture Inc.), 6317 Woods Drive, Nanaimo, BC V9V 1H4
Contact: 250-331-1931 | info@d-architecture.ca
Project No: 2009
Scale: 1/8" = 1'-0"
Date: April 28th 2015
Client: Danfor Investments Inc.
Sheet Number: A3.1

Interior Elevation North

Interior Elevation North showing a four-story residential building facade with multiple balconies and sloped roof segments.

Section BB

Interior Elevation West

Section GG
