Sign Plan Index and Signage Specifications

June 14, 2016Pages 256–2623 sections

Inventory and design specifications for all commercial signage at Admirals Walk.

2 APPROVAL OF AGENDA
Graphic FX Sign Works

SIGN PLAN INDEX

Aerial view of the shopping center showing numbered locations from 1 to 40 for building signage.
Aerial view of the shopping center showing numbered locations from 1 to 40 for building signage.
Page 256–262

Sign Specifications

Signs 1-12

Graphic design layouts and dimensions for signage numbers 1 through 12.
Graphic design layouts and dimensions for signage numbers 1 through 12.
Sign # Text / Business Name Color Dimensions (Width x Height)
1 PHARMASAVE (Compounding Pharmacy / Home Health Care) Red 407" x 30"
2 PHARMASAVE Red 187" x 30"
3 SELECT MORTGAGE Purple 302" x 30"
4 Your Pet Pals Blue 160" x 30"
5 THE FRAME FACTORY Green 180" x 32"
6 STRONGER Curves TOGETHER Purple 216" x 30"
7 DRYCLEANERS AVALON LAUNDROMAT Black/Yellow 287" x 30"
8 DOLLAR STORE Red 218" x 30"
9 DOLLAR STORE Red 218" x 30"
10 BCSPCA Thrift Stores Purple 190" x 30"
11 PET CLINIC Dark Grey 90" x 30"
12 PET CLINIC Dark Grey 130" x 30"

Signs 13-25

Graphic design layouts and dimensions for signage numbers 13 through 25, including generic placeholders and restaurant signs.
Graphic design layouts and dimensions for signage numbers 13 through 25, including generic placeholders and restaurant signs.
Sign # Text / Business Name Color Dimensions (Width x Height)
13 SIGNAGE Black 240" x 20"
14 SIGNAGE Black 228" x 20"
15 SIGNAGE Black 162" x 20"
16 SIGNAGE Black 162" x 20"
17 SIGNAGE Black 205" x 20"
18 SIGNAGE Black 218" x 20"
19 SIGNAGE Black 210" x 20"
20 mokahouse COFFEE Black 230" x 30"
21 SUBWAY Black 162" x 30"
22 SUBWAY Black 306" x 30"
23 mokahouse COFFEE Black 306" x 30"
24 mokahouse COFFEE Black 382" x 30"
25 SUBWAY Black 382" x 30"

Signs 26-40

Graphic design layouts and dimensions for signage numbers 26 through 40, including liquor store and various professional services.
Graphic design layouts and dimensions for signage numbers 26 through 40, including liquor store and various professional services.
Sign # Text / Business Name Color Dimensions (Width x Height)
26 four mile LIQUOR STORE Black 288" x 30"
27 four mile LIQUOR STORE Black 257" x 30"
28 four mile LIQUOR STORE Black 282" x 30"
29 four mile LIQUOR STORE Black 142" x 30"
30 Second Slice PIZZA Red 182" x 30"
31 ULTIMATE WATER Blue 128" x 30"
32 ULTIMATE WATER Blue 67" x 30"
33 ADMIRALS WALK / DENTAL Orange/Blue (94" + 176") x 30"
34 Admirals Walk OPTOMETRY CLINIC Blue 258" x 30"
35 Achieve Health Grey 182" x 30"
36 WINE KITS Brown 154" x 30"
37 ISLAND LAB SERVICES Blue 146" x 30"
38 BEAUTY NAILS & SPA Pink 207" x 30"
39 LITTLE TOKYO Red 252" x 30"
40 LITTLE TOKYO Red 252" x 30"
Page 256–262

Building Elevations

Signs 1-19 Elevations

Architectural elevations showing the placement of signs 1 through 19 on the main building facade.
Architectural elevations showing the placement of signs 1 through 19 on the main building facade.

Signs 20-25 Elevations

Architectural elevations showing the placement of signs 20 through 25 on the standalone coffee and restaurant building.
Architectural elevations showing the placement of signs 20 through 25 on the standalone coffee and restaurant building.

Signs 26-40 Elevations

Architectural elevations showing the placement of signs 26 through 40 on the liquor store and adjacent service units.
Architectural elevations showing the placement of signs 26 through 40 on the liquor store and adjacent service units.
