Appendix
Attachment 3. BC Land Surveyors Site Plan - 2 Hospital Way
May 10, 2022Page 1581 section
Survey plan showing the approximate parking area highlighted and cross-hatched.
2 Hospital Way
Appendix A
BC LAND SURVEYORS SITE PLAN OF
Civic: 2 Hospital Way Parcel A (DD 137075-I), Block 1, Section 100, Esquimalt District, Plan 1066, except part in Plans 43365, VIP62916 and VIP62917 Parcel Identifier: 003-312-833 Prepared for: Associated Building Credits LTD SCALE 1 : 1250 (11x17 sheet) All distances are shown in metres.
- Approximate Parking area – highlighted and cross hatched
- Parking area to be accessed only via Hospital Way gate area
Plan Designations and Labels:
- HOSPITAL WAY
- Hayter Way
- C-1 ZONE 1.76 ha
- PART PARCEL 2.88 hectares
- P-2 ZONE 0.92 ha
Page 158
