Tree Removal & Retention Plan
A landscape survey identifying existing trees on the site that are slated for retention, removal, or potential removal.
Tree Removal & Retention Plan
Project Information
Project: EAGLES NEST RESIDENCES Location: HELMCKEN & WEST BURNSIDE ROADS, VIEW ROYAL, BC Client: BOARDWALK DEVELOPMENT, 200 – 1501 1 ST. SW, CALGARY ALBERTA, T2R 0W1 Sheet Title: Tree Removal & Retention Plan Sheet No: L0.01 Project No: 121.33 Scale: 1: 250 @ 24"x36" Drawn By: EB Checked By: SM/JD Status: NOT FOR CONSTRUCTION
Landscape Architect: Murdoch de Greeff inc. Landscape Planning & Design 200 - 524 Culduthel Road Victoria, BC V8Z 1G1 Phone: 250.412-2891 Fax: 250.412-2892
Revisions
| rev no | description | date |
|---|---|---|
| 1 | DP | 2021-10-29 |
Drawing Notes
- DO NOT SCALE DRAWING: Verify all property lines and existing structures/vegetation to remain, prior to commencing work.
- All plan dimensions in metres and all detail dimensions in millimetres.
- Plant quantities on Plans shall take precedence over plant list quantities.
- Contractor to confirm location and elevation of all existing services and utilities prior to start of construction.
- Provide layout of all work for approval by Landscape Architect prior to proceeding with work.
- Contractor to provide irrigation system for all planters to current IIABC Standards and Contract Specifications.
- Landscape installation to carry a 1 year warranty from date of acceptance.
- Plant material, installation and maintenance to conform to the current edition of the Canadian Landscape Standard.
- General Contractor and/or sub-contractors are responsible for all costs related to production and submission to consultant of all landscape as-built information including irrigation.
- Tree protection fencing, for existing trees, to be installed prior to commencement of all site work.
Legend
- Property line: (indicated by solid red line)
- Right of Way: (indicated by dashed red line)
- 24.31: Existing Landscape Grade
- 23.77: Architectural grade, provided for reference only
- 23.75: Proposed Landscape Grade
Landscape Abbreviations:
- TW: Top of Wall
- BW: Bottom of Wall
- TOC: Top of Curb
- BC: Bottom of Curb
- TP: Top of Pool
- BP: Bottom of Pool
- TS: Top of Stairs
- BS: Bottom of Stairs
Tree Retention and Removal Categories:
- Existing Tree to be Retained: Indicated by a green circle with Tree Tag # and Critical Root Zone (CRZ).
- Existing Tree Potentially Removed: Indicated by a yellow circle with Tree Tag # and Critical Root Zone (CRZ).
- Existing Tree to be Removed: Indicated by a red circle with 'X', Tree Tag #, and Critical Root Zone (CRZ).
Site Plan Overview
The drawing provides a detailed plan for tree retention and removal for the Eagles Nest Residences project. The site is bounded by Helmcken Road to the south and Burnside Road to the east. The plan shows building footprints, site elevations, and the locations of numerous cataloged trees.
- Retained Trees (Green Circles): These are primarily located along the property perimeters, including tree tags #21 through #34, #35 through #58, #60 through #65, #75 through #79, #NT1 through #NT5, and #NT6.
- Potentially Removed Trees (Yellow Circles): Includes tree tag #59.
- Removed Trees (Red Circles with X): Numerous trees situated within or near the proposed building footprints are marked for removal, including tags #1 through #20, #68 through #74, #80 through #94, #96, #176, and #NT7 through #NT10.
The plan includes a graphic scale bar (0 to 20m) and a North arrow indicator.
