Appendix
Eagles Nest Residences Site Plan
February 8, 2022Page 3551 section
An architectural site plan for the proposed Eagles Nest Residences development showing building heights ranging from 3 to 6 storeys.
dHKarchitects235 apartment units proposed3, 4, 5, and 6 storey buildingsJanuary 22, 2020
Eagles Nest Residences - Site Plan
Project: Eagles Nest Residences Location: Helmcken Rd, View Royal BC Architect: dHKarchitects Project Number: 1827 Drawing Number: A101 Plot Date: 22 JAN 2020 Scale: 1:250 Drawn by: EDS Checked by: RAW
Revision History
| Date | Description |
|---|---|
| 17 SEP 2018 | ISSUED FOR REZONING |
| 28 JUN 2019 | RE-ISSUED FOR REZONING |
| 22 JAN 2020 | RE-ISSUED FOR REZONING |
Site Plan Details
The site plan illustrates the proposed development layout, including building heights, landscaping, and key site features.
Building Heights:
- 6 Storeys
- 5 Storeys (multiple locations)
- 4 Storeys (multiple locations)
- 4 Storeys (with partial 5th floor)
- 3 Storeys (multiple locations)
Site Features and Landscaping:
- Community Green
- Woonerf
- Feature Rain Garden
- Preserved Rock Outcrop
- Preserved Trees and Landscape
- Property lines are indicated along Burnside Road and Helmcken Road.
General Notes:
- All dimensions are shown in millimeters.
- The drawing includes a North arrow and a sun path diagram for June and December.
Contact Information
Victoria Office 977 Fort Street Victoria BC V8V 3K3 T 1 • 250 • 658 • 3367
Nanaimo Office 102 - 5190 Dublin Way Nanaimo BC V9T 0H2 T 1 • 250 • 585 • 5810
Page 355
