Committee of the Whole/Documents/Elevations and Floor Plans for 335 Stewart Avenue
Appendix

Elevations and Floor Plans for 335 Stewart Avenue

November 8, 2022Pages 165–1671 section

Architectural drawings showing the height dimensions and interior layout of the proposed addition.

Attachment 5, Pages 4-6Living area noted as 1034 SQ FT
Architectural cross-section drawing showing building heights, interior floor levels, and roof slopes
Architectural cross-section drawing showing building heights, interior floor levels, and roof slopes

[Architectural floor plan showing building footprint, staircases, and window/door labels]

LIVING AREA 1034 SQ FT

Labels and Specifications:

  • 3068
  • 4040FX
  • 4430FX
  • 5068FX
  • 7052FX
  • 7072FX
  • 7080FX
  • 7768FX
  • 8 0FX
  • 8040FX
  • 8040TC
  • 8863FX
  • 10068FX
  • 11668FX
  • 12068
  • UP
Architectural elevation drawing showing exterior window arrangements and roof profiles
Architectural elevation drawing showing exterior window arrangements and roof profiles
Page 165–167
Extracted from: 2022 11 08 Committee of the Whole Agenda - Agenda - Pdf
