Committee of the Whole/Documents/Attachment 3: Site Plan - 1681 Island Highway
Appendix

Attachment 3: Site Plan - 1681 Island Highway

November 8, 2022Page 2454 sections

Architectural site plan showing the Burger King building and the locations for the new pre-order and menu boards.

1681 Island HighwayDrawing A5.1June 2012 (last revision Sept 2012)

Project Statistics
MUNICIPAL ADDRESS 1681 OLD ISLAND HIGHWAY, VIEW ROYAL, BRITISH COLUMBIA
LEGAL DESCRIPTION
ZONING C-1
SITE AREA
EXISTING SITE AREA TO REMAIN THE SAME 55,391.46 SQ. FT. (5146.1 SQ.M.)
BUILDING AREA
BURGER KING 4,605.87 SQ. FT. (427.9 SQ.M.)
RETAIL BUILDING 3,878.34 SQ. FT. (360.3 SQ.M.)
F.S.R.
EXISTING AREAS TO REMAIN THE SAME 0.15
15% (8,484.21 / 55,391.46)
PARKING
REQUIRED:
DRIVE THRU RESTAURANT 1 STALL PER 13 SQ.M. = 32.9 STALLS
RETAIL SPACE 1 STALL PER 20 SQ.M. = 18.0 STALLS
TOTAL REQUIRED STALLS = 51 STALLS
EXISTING: 65 STALLS
PROPOSED: 65 STALLS - NO CHANGE
Page 245

Site Plan Notes

  1. THESE DRAWINGS ARE COMPILED FROM INFORMATION SUPPLIED BY OWNER AND CONFIRMED BY SITE VERIFIED BY CONTRACTOR AT BID TIME.
  2. CONTRACTOR TO VERIFY ALL SITE CONDITIONS AND DIMENSIONS PERTINENT TO WORK BEING PERFORMED, PRIOR TO STARTING CONSTRUCTION, AND REPORT ANY DISCREPANCIES OR VARIANCES.
  3. ALL WORK SHALL CONFORM TO THE REQUIREMENTS OF LOCAL CODES.
  4. MAKE GOOD ALL EXISTING THAT IS DISTURBED BY NEW WORK.
  5. GC RESPONSIBLE FOR ANY REPAIRS OR RELOCATION ASSOCIATED WITH CURBS/ASPHALT/BASE WORK.
  6. ALL EXISTING ASPHALT PAVING AND CONCRETE CURBS ARE TO BE RETAINED. CONTRACTOR IS RESPONSIBLE FOR ALL DAMAGE. CONTRACTOR IS TO REPAIR TO MATCH EXISTING AT NO COST TO OWNER.
  7. ALL EXISTING CONCRETE SIDEWALKS ARE TO BE RETAINED. CONTRACTOR IS TO REPAIR/REPLACE ANY CRACKS AND IS RESPONSIBLE TO REPAIRING ALL DAMAGE TO SIDEWALKS TO THE SATISFACTION OF OWNER.
  8. EXISTING CURBS AND ASPHALT THAT ARE REMOVED AS NOTED, MAKE GOOD TO MATCH ADJACENT AREA.
  9. NEW ASPHALT IN ALL AREAS EXPOSED TO BE REPAIRED TO MATCH EXISTING.
  10. REMOVE EXISTING ASPHALT BELOW NEW CURBS AND ISLANDS.
Page 245

Signage Notes

Sign Installer Responsibilities:

  1. PROVIDE ALL DRAWINGS NECESSARY FOR SIGN PERMITS.
  2. APPLY FOR, OBTAIN AND PAY FOR ALL REQUIRED SIGN PERMITS.
  3. COORDINATE EXCAVATION OF SIGN FOUNDATIONS WITH G.C.
  4. SET ANCHOR BOLTS OR BASE PLATES AS REQUIRED.
  5. COMPLETE SIGN INSTALLATION.
  6. REMOVE EXCESS DEBRIS, ROUGH GRADE AREA FOR LANDSCAPING.

General Contractor Responsibilities:

  1. COORDINATE EXCAVATION OF SIGN FOUNDATIONS WITH SIGN SUPPLIER.
  2. PROVIDE POWER TO ALL SIGN LOCATIONS AS REQUIRED.
  3. MAKE FINAL ELECTRICAL CONNECTIONS TO EACH SIGN.
Context Plan aerial view showing the location of the existing Burger King at 1681 Old Island Hwy, View Royal, BC
Context Plan aerial view showing the location of the existing Burger King at 1681 Old Island Hwy, View Royal, BC
Page 245

Project Information

Architect: PJLOVICK ARCHITECT LTD 3707 1st AVENUE, BURNABY, BRITISH COLUMBIA V5C 3V6 tel: 604-298-3700 fax: 604-298-6081

Project: BURGER KING 1681 OLD ISLAND HIGHWAY, VIEW ROYAL, B.C.

Drawing: SITE PLAN
PROJECT NUMBER 12-25
DRAWING NUMBER AS1
DATE JUNE 2012
SCALE 1/16" = 1'-0"

Revision History:

  • SEPT. 1/12: ISSUED FOR BUILDING PERMIT
  • AUG. 23/12: REISSUED FOR DEVELOPMENT PERMIT
  • JUL. 30/12: ISSUED FOR DEVELOPMENT PERMIT
Page 245
