SITE PLAN OF PART OF LOT 1, BLOCK 9, SECTIONS 8 AND 27

March 18, 2014Page 231 section

A detailed surveyor's site plan for the property at 281 Pallisier Ave showing property lines and the retaining wall.

1 CALL TO ORDER
December 13, 2013Island Land Surveying Ltd.Shows retaining wall offsets

SITE PLAN OF PART OF LOT 1, BLOCK 9, SECTIONS 8 AND 27, ESQUIMALT DISTRICT, PLAN 1688

SCALE 1:100 All distances are in metres. (Scale bar shows 0 to 10 units)

Notes:

  • This site plan is prepared for Variance application only.
  • CGVD28 geodetic elevations were derived from observations to geodetic control monument VROB-10 (Elevation=10.99).
  • Plan dimensions were derived from Posting Plan 4131.

LEGEND

  • Field survey dated this 10th day of December, 2013.
  • Civic address: 281 Palliser Avenue
  • Offsets shown are to exterior retaining wall.
  • PID: 007-090-803

NOTE: A comprehensive legal survey may reveal offsets to boundaries that differ from those shown.

Dated this 13th day of December, 2013 Peter I. M. Broeren, BCLS

P16

Site plan of part of Lot 1, Block 9, Plan 1688, Esquimalt District. The plan shows Lot 1 with an area of 760 sq.m. and an "AMENDED" Lot 2. The property is bounded by Pallisier Avenue and Beaumont Avenue. The diagram includes detailed measurements for property lines, retaining walls, and a gravel parking area, along with a north arrow.
Site plan of part of Lot 1, Block 9, Plan 1688, Esquimalt District. The plan shows Lot 1 with an area of 760 sq.m. and an "AMENDED" Lot 2. The property is bounded by Pallisier Avenue and Beaumont Avenue. The diagram includes detailed measurements for property lines, retaining walls, and a gravel parking area, along with a north arrow.

Project Details:

  • File: 35A-MAZZA-SP1
  • Date: December 13, 2013
  • Island Land Surveying Ltd.
  • 1-15 Cadillac Avenue, Victoria, B.C. V8Z 1T3
  • TEL 250.475.1513 FAX 250.475.1516
  • www.islandsurveying.ca
